• Suitable for setting horizontal and vertical mitre angles of cutting machines
• Buttons: ON/OFF, HOLD/SUP, SPR/CNR/MTR/BVL
• IP54 dust/waterproof



• Clockwise and counter-clockwise operation
• Memory of 250 results, can upload to the computer
• Back with magnet



• Quickly measure major, pitch and minor diameters of external thread
• Suitable for metric, inch, whitworth, NPT and BSPT



• For inspection of GO, NO-GO and depth of threads
• Can be for repair of thread defects
• Real-time display of torque, circles, OK and NG counts



• Meet ISO3650/grade 2
• Supplied with manufacturer inspection certificate



• Made of ceramic, extremely wear resistance and corrosion resistance, excellent dimension stability
• Meet ISO3650
• Supplied with manufacturer inspection certificate



• Made of alloy steel
• Meet ISO3650
• Gauge blocks ≥125mm have clamping holes



• Measure the crest diameter of internal thread with nominal diameter larger than 2 3/8" (60.325mm) and less than 5 1/2" (139.7mm)



• Measure the height of rotary shouldered internal thread connections



• Measure the height of internal thread with nominal diameter less than 5 1/2" (139.7mm)



• Measure the taper of internal thread
• Digital indicator stroke: 25.4mm/1"



• Measure the pitch diameter of lead screw and external thread
• Ball tip diameter can be customized according to workpieces. Diameter of trapezoidal screw or external thread ball tips: ØD=0.5×pitch P/cos (thread angle α/2)
• Ball tips diameter ØD of ball screw is corresponding steel ball specification



• Measure thickness of leather
• Buttons: on/off, inch/mm, zero, data preset, change measuring direction, absolute/incremental measurement
• Keep preset data in memory after restart



• Measure thickness of geomembranes
• Button function: on/off, inch/mm, zero, data preset, change measuring direction, absolute/incremental measurement
• CR2032 battery, automatic power off (time is adjustable)



• Measure thickness of vulcanized rubber and plastic products
• Button function: on/off, inch/mm, zero, data preset, change measuring direction, absolute/incremental measurement
• CR2032 battery, automatic power off (time is adjustable)



• Absolute encoder, the original data remains after power off
• Button function: on/off, zero, tolerance, absolute/incremental measurement, max./min./TIR, data preset, mm/inch, data output, data hold
• Reading in digital and analog
• Power: rechargeable battery, for 12 hours continuous working



• Reading in digit and analog
• Display can be rotated by 170°
• Button function: tolerance Go and No-Go display, data preset, max./min. measurement, data holding, inch/metric conversion, absolute/incremental measurement



• Reading in digit and analog
• Display can be rotated by 170º
• Button function: tolerance Go and No-Go display, data preset, max./min. measurement, data holding, inch/metric conversion, absolute/incremental measurement



• Button function: on/off, zero, mm/inch, measuring direction change, data preset, absolute/incremental measurement
• Vertical travel of holder: 150mm
• Fine adjustment range: 2mm



• Non-magnetic and hardened base
• Suitable for granite surface plates or cast iron surface plates
• For 0.001mm and 0.01mm dial and test indicators
