• Zero-setting, weighing, subtracting tare value, simple counting
• LCD display, with backlight
• Unit: g, ct, ozt, oz, GN, dwt, lb, kg



• Buttons: on/off, zero, mm/inch, max./min./max.-min.
• High response speed (5000mm/s)
• High brightness LED display



• Non waterproof
• Buttons: on/off, set, mm/inch, preset (+, -)
• Automatic power off, move the digital unit to turn on power



• Cross roller guides, achieve high precision and smooth movement
• Coarse and fine adjustments
• Precise angle adjustment



• Horizontal rotary: range 360°, graduation 0.05°
• Vertical incline: range 45°, graduation 0.05°
• With vertical incline adjust knob



• Accuracy of angle: ±15 seconds
• Made of SKS tool steel, subzero treatment
• Hardness HRC58-60



• Accuracy of angle: ±15 seconds
• Made of alloy tool steel
• Hardness HRC58-60



• Made of tool steel
• Hardened to HRC56-58



• Hold cylindrical workpieces for inspection and machining
• To be used on magnetic chucks
• Two V-blocks per set



• Vertical travel of holder: 250mm
• Fine adjustment range: entire stroke
• Supplied with dust cover



• Vertical travel of holder: 300mm
• Fine adjustment range: 5mm
• Carbide base



• Digital caliper, range 0-150mm/0-6", resolution 0.01mm/0.0005" (code 1108-150)
• Digital outside micrometer, range 0-25mm/0-1", graduation 0.001mm/0.00005" (code 3109-25A)
• Dial test indicator, range 0.8mm, graduation 0.01mm (code 2380-08)



• Digital caliper, range 0-150mm/0-6", resolution 0.01mm/0.0005" (code 1108-150)
• Outside micrometer, range 0-25mm, graduation 0.01mm (code 3202-25A)
• Dial indicator, range 10mm, graduation 0.01mm (code 2308-10A)



• For repairing of calipers, micrometers and indicators
• Magnetizer and demagnetizer
• Pointed tweezer, 125mm



• Includes: 4pcs "–": 1.4mm, 2.0mm, 2.4mm, 3.0mm, 2pcs "+": 0#, 1#
• Rotating cap
• Material: CRV, hardness: HRC52~56



• Center head (made of cast iron): to locate center of cylinders with diameter (Ød): 30-100mm, accuracy: ±0.15mm
• Protractor head (made of cast iron): set the blade at desired angle to an edge of a workpiece, and can be used to measure angles range: 0-180°, accuracy: ±20min



• Button function: on/off, m/ft, HOLD, reset, stake out, memory
• Nylon+glass fiber plastic frame, wear-resistant TPU tire
• Can store 99 groups of measurement data



•



• Welding gauge (code 4834-1)
• Welding gauge (code 4851-1)
• Fillet welding gauge, size 3~25mm, 7 blades (code 4836-1)



• Non waterproof
• Buttons: on/off, set, mm/inch, preset (+, -)
• Automatic power off, move the digital unit to turn on power
