Curatator conectoare fibra optica Shineway CLN-10/ CLN-20

• Full duplex multiparty call on single fiber
• Combines laser source and power meter
• High-quality voice signal
• Large internal memory: 4000 records
• PC software for data download and reporting



• Clear TFT LCD display (320*240)
• 8-channel measurement (1471-1611 nm)
• Result display in histogram and list
• Data Transfer to PC via USB
• 10 hours continuous operation



• Support quick test, intelligentized operation
• Graphic interface, large easy to read LCD display
• Measurement units in dB, dBm and W (or mW)
• Large memory capacity (4000 measurements)
• Interchangeable fiber-optic adapters (FC, SC, ST, P/N, E 2000)
• RS-232 data upload port



• ITU-T G.650 recommended method for PMD characterization:
• Accurate total PMD, PMD coefficient
• Fully support 10G/40G/100G DWDM optical network upgrade test
• Compliant with G.650.2, EIA/TIA FOTP-124 & IEC-61941
• High dynamic range for long span measurement 40dB or 200Km
• Easy to use touch screen
• External ports: RG45x1, RS232x1, USBx2, VGAx1



• 5.7" Turn-over LCD screen for clear display Both X and Y axis display
• Fiber core can be display clearly
• Inner light to set fiber in dark environment Auto check fiber end-face
• Auto calculate splicing loss
• 9 seconds splice time and selectable heating mode
• 3 hours fast recharge
• 60 preset/user-definable splicing programs



• Specially designed for FTTx/PON (B/E/G) applications
• Simultaneous Triple-play PON signals measurement: 1310/1490/1550nm (Voice/Data/Video)
• Pass/Warning/Fail assessment
• Pass-through test: Applicable anywhere on PON
• Optional Visible Fault Locator for macro bend detection and fiber identification
• Optional SM/MM Power Meter and Stabilized Laser Source



• Available for SC, FC, ST, etc. connectors
• Suitable for both field use and factory use
• Consistently achieve high quality cleaning without alcohol or other solvents
• Cleaning tape is replaceable, thus reducing long-term cost
• One cleaning tape can be used for over 600 wipes/reel



• Auto and manual splicing
• Splicing=9s, heating=25s(time and power adjustable)
• Arc counter prompts electrode change upon usage
• Auto arc optimization



• OPM-15 Optical Power Meter
• SLS-21 Stabilized Laser Sources
• Applicable on singlemode/multimode fibers
• Quick response, no warm-up
• Interchangeable connectors: FC/SC/ST



• Network/BER testing
• Power meter calibration
• Link loss simulation
• Optical margin analysis
