Kit accesorii sudura fibra optica PROMAX OP-040B

• theoretical-practical study of a DVD & CD player
• observe the internal composition of the mechanics
• analyze the signals that take part of the operation
• simulate several faults for the study of troubleshooting and diagnostic methods



• PAL B/G, D/K, I, N, NTSC M, SECAM B/G, D/K, L Standards
• Direct acces keys for nine different chars
• 4:3 & 16:9 formats
• Addition of an electronic circle
• Double side band modulation



• test the frequency response of an entire television system prior to having the antennas or the Headend installed
• can be used for the test and certification of TV and satellite wiring, headend trouble shooting
• 1050 / 1575 / 2100 MHz L BAND TEST PILOTS
• 537.5 MHz UHF TEST PILOT



• H.264/AVC (MPEG-4 part 10), High profile, Level 4.0, 4:2:0 Chrominance sampling
• TS to TS Transcoding (MPEG-2 HD to H.264 HD/SD or MPEG-2 SD to H.264 SD)
• MPEG-1 Audio Layer1 & Layer2 encoding
• 1x Dolby Digital (AC-3) or 1x MPEG-1 audio pass through transcoding
• Supports full HD 1080i encoding
• HD-SDI, HDMI, YPbPr/RGB video input interface



• measuring simultaneously three wavelengths (1310, 1490 and 1550 nm) in FTTH / PON systems
• optimized for GPON architecture
• Visible Fault Locator by laser emission
• Data transfer to PC
• Graphical interface simple and very intuitive, easy-to-use



• TS INPUT: 2 DVB-ASI independent inputs
• RF OUTPUT: 2 independent combined DVB-T multiplex
• Filtering table up to 32 PID
• Measurement: Bitrate of the output multiplex
• includes an internal combiner that delivers a single DVB-T output with high C/N



• integrated DVB-T tuner that allows the TS capture in real time
• record a transport stream continuously for several minutes and then play it back
• work in the field where maybe it is not possible to find electricity available
• ASI Transport Stream Input: Maximum data rate 40 Mb/s
• RF Input: DVB-T from 35 to 100 dBµV
• ASI & SPI parallel Transport Stream Output: Maximum data rate 32 Mb/s
• Storing Capacity: Memory card 4 GB, 20 minutes approx (20 Mbits/s)



• OPTICAL INPUT: From 1100 to 1600 nm
• RF OUTPUT: From 470 MHz to 862 MHz
• optical SC input and an RF type BNC output
• suitable for optical links up to 40 km away



• RF INPUTS: 2 independent DVB-T inputs
• RF OUTPUT: 2 combined independent DVB-T multiplexes
• PID Filtering with Filtering Table up to 32 PID
• direct COFDM input that can be tuned to any multiplex
• ouput in the UHF band
• regenerate the quality of the multiplex when received from a noisy source
• change the input channel to another channel with total quality preservation



• measure the basic parameters to determine the quality of the signal in a CATV system
• different options depending on the needs
• one hand operation instrument with direct reading of the measurement
• illuminated LCD screen
• audio demodulator together with an speaker
• exchangeable input connector so to avoid damaging the instrument
