Control / wiring practices for PLC I/O module and sensor application module
Applied experiments on binary data in utilization of the FND/Digital switch
Serial communication between external devices and MPI port (Touch Panel)
Basic level of Inverter’s operation / Inverter control using analog
Multi-step speed control and rotating direction control using the Inverter and PLC
Advanced programming experiments and utilization of external devices in liaison with sensors

Features:

Comprehensive experiments on PLC, Inverter, Touch Panel and Sensor
Various programming experiments including digital numeric value
Aluminum case structure for convenient storage and mobility
Built-in DC power supply as part of system for handy practices
All-in-one training system which comes with the inverter and touch panel

Alte produse ED

COMPUTER BASED INSTRUMENT SYSTEM CBIS-1400

• PC-based multi-function instrument for electricity/electronics and other experiments
• Digital Storage Oscilloscope with the 2-channel simultaneous 50MS/s sampling rate
• Spectrum Analyzer functions using Digital Storage Oscilloscope(DSO)
• Variable Power Supply(VPS), Function Generator(FG), Analog Output and Digital Output
• Analysis of collected data on PC through the modules of DSO, DMM, FC and Analog/Digital Input
• Numerical and graphical indication of the data measured and analyzed in real time

SYNCHRONOUS MOTOR(3-PHASE)/DC GENERATOR MG-5215

• Start and Sync characteristics of synchronous motor
• V-curve characteristics of synchronous motor
• Synchronous motor’s loss and efficiency
• Load characteristics of self-excited shunt-wound generator

ANTENNA TRAINER ED-3200

• 16 different types of Antenna
• RF source generation : 500MHz, 2GHz and 10GHz
• Software simulation of radiation Patterns and characteristics of Antenna
• Antenna Directional Coupler (Manual / Remote)

SENSOR APPLICATION TRAINER ED-6800B

• Inverting, Non-inverting and Differential Amplifiers
• Comparator Circuit
• Voltage and Current Circuit

NEW & RENEWABLE ENERGY TRAINER ED-9710

• Conversion processing experiments on the produced energy(power production / processing)
• Energy efficiency experiments followed by energy production and conversion
• Voltage and current characteristics curve
• Standalone or integrated operation of the energy experimental module
• Enriched teaching aids such as simulation software for power production

LAN TRAINING SYSTEM ED-NET-3

• Panel type structure for good grasp of entire network configuration
• Learning about the functions and characteristics of basic network equipments such as NIC, HUB, Router and DSU, plus installation and maintenance
• Interlocking experiments with Internet for clear understanding a real network
• Capable of conneting to the open network on campus

SENSOR TRAINER FOR FACTORY AUTOMATION ED-6830

• Integrated sensor training system covering electricity, electronics, automation and chemistry
• Consists of 24 sensor modules, 8 application modules, 5 conversion modules, 2 signal prossing modules, 11 pneumatic components and power supply
• PC-based control for convenient, effective data collection and analysis
• Application module experiments(illumination, pneumatic auto coor, motor, temperature) for enhancing field experiences

SMALL DESKTOP TYPE PLC TRAINER ED-4260MD

• Small desk type structure for space optimization
• Built-in DC power supply for convenience
• Handy experiments on the basic and application programming commands
• Base structure capable of expansion by mounting the special modules

HOME NETWORK DESIGN PLATFORM ED-5965

• Designed to help develop network devices on the basis of Lon Protocol
• Control of each device installed in the field through power line communication
• Related experiments through Neuron C and MICOM programming
• Home network control in utilization of LabVIEW

OP-AMP CIRCUIT TRAINER ED-6000

• OP-Amp. characteristics and various appplication circuits
• Main Frame contains DC Power Supply, AF Signal and Frequency Counter
