Op-Amp Circuit Trainer ED-6000

Cod: ED-6000




Brosura produs PDF, 0.56 Mb

Descriere

SPECIFICATIONS

EXPERIMENTAL MODULE(7ea)

  • NO-6011(1ea) : OP-AMP Characteristics
  • NO-6012(1ea) : Basic Linear Amp
  • NO-6013(1ea) : Differentiator and Integrator
  • NO-6014(1ea) : Voltage and Current Circuit
  • NO-6015(1ea) : Non-Linear Signal Processing
  • NO-6016(1ea) : Generator
  • NO-6017(1ea) : Active Filter
  • Bread Board
    • Socket Strip(630 holes) : 2ea
    • Bus Strip(100 holes) : 3ea
  • Module Size : 198(W) x 14(H) x 108(D)mm
  • System Weight : 12kg



MAIN FRAME ED-2200(U)

  • DC Output : 5/6V, 9/12/15V(Dual Output)
  • Decade Capacitor : 0.001~0.1µF(2 digits)
  • Prog. Resistor : 10k?~1.5M?(2-BCD)
  • Variable Resistor : 1/100k?(2ea)
  • Current : 0~10mA/100mA(2 ranges)
  • Protection : DC overload alarm & indication
  • Speaker : 8?, 1W
  • Input Voltage : AC 220V, 50/60Hz
  • Dimension : 350(W) x 85(H) x 355(D)mm
  • Weight : 7.2kg



ACCESSORIES

  • Jumper Wire(5-color) : 1set
  • Operating Manual : 1ea
  • Experimental Manual : 1ea
