RIGOL DM3058E Multimetru digital de precizie

Cod: RIGOL DM3058E




Brosura produs PDF, 0.26 Mb

Descriere

DM3068          6 1/2 digit DMM

DM3058E       5 1/2 digit DMM

DM3058          5 1/2 digit DMM



  • True 5 ½ or 6 ½ digit resolution
  • Up to >8,000 Readings per second
  • GPIB, USB, RS-232, and LXI-C (Ethernet) Connectivity
  • SCPI Command Compatibility
  • Available datalogging and sensor connectivity





The DM3000 Series DMMs give reliable, cost effective, full DMM capabilities measuring DCV, ACV, DCI, ACI, Resistance (2 & 4 Wire), Capacitance, Diode Test, Frequency, and Temperature. These DMMs are designed for simple and efficient bench top use, but include software options for datalogging and remote programming from almost any interface. The DM3000 can fit any DMM application with speed, accuracy, reliability, and efficiency well beyond its price.



Model



DM3058

DM3068

Measurement Function

Range

Accuracy: 1 Year ± (%of reading +%of range)

Accuracy: 1 Year ± (%of reading +%of range)

DC Voltage

200 mV - 1000 V

0.015 + 0.003

0.0035+0.0005

DC Current

200 uA - 10 A

0.055+0.005

0.050+0.005

AC Voltage (RMS)

200 mV - 750 V

0.20 + 0.05

0.06+0.03

AC Current (RMS)

20 mA - 10 A

0.30+0.10

0.10+0.04

Resistance(2-wire and 4-wire)

200 O - 100 MO

0.020 + 0.003

0.010+0.001

Capacitance

2 nF - 10000 uF

1 + 0.5

1 + 0.5

Diode

2.4V

0.05 + 0.01



Continuity

2 kO

0.05 + 0.01



Frequency and Period

200 mV - 750 V

0.01+0.003

0.007
