Encoder Video DVB HDTV H.264/AVC Promax EN-260

Cod: Promax EN-260




Brosura produs PDF, 0.14 Mb

Descriere

PROMAX EN-260 is an affordable DVB H.264/AVC Encoder. It includes HDMI, YPbPr  (component) and CVBS (composite video) inputs and offers TSoIP or TS-ASI outputs. Because of its excellent enconding performance, bandwidth efficiency and moderate price it is an ideal solution to add High Definition to your programme roaster. Applications include but are not limited to Hotels, ships, convention centres, hospitals, Cable TV networks, etc.

  • H.264/AVC video encoding
  • HDMI, YPbPr, composite video input interface
  • MPEG-1 Audio Layer1 & Layer2 encoding
  • TS over IP  and TS-ASI outputs
  • Ethernet remote control



VIDEO?INPUT
  Video input interface
  Video Compression
  Bit rate
  Frame rate
  Resolution


HDMI, YPbPr (component), CVBS (composite video)
H.264
20 Mbps (max.)
1 fps to 25/30 fps
1920x1080: 60p / 59.94p / 50p / 60i / 59.94i / 50i
1280x720: 60p / 59.94p / 50p
720x576: 50i[P]
720x480: 59.94i[N]

AUDIO?INPUT
  Audio input Interface
  Audio Compression Format


Stereo female BNC
MPEG-1 Audio Layer 1 & Layer 2 encoding

TS I/O
  MPEG over IP
  ASI output


10/100Mbps T-base, RJ45, RTP over UDP, Multicast
BNC×1, 75 O



Optiuni recomandate





Alte produse PROMAX

ENCODER VIDEO DVB HDTV H.264/AVC PROMAX EN-260

• H.264/AVC video encoding
• HDMI, YPbPr, composite video input interface
• MPEG-1 Audio Layer1 & Layer2 encoding
• TS over IP and TS-ASI outputs
• Ethernet remote control



SISTEM TRAINING RECORDER CASETE PROMAX EG-833

• Input section
• Recording process section
• Playback process section
• Output section
• Noise reduction systems: Dolby© B and C
• Control system



PLATFORMA TRAINING COMUNICATII FIBRA OPTICA PROMAX EF-970

• EMITTER KIT: Two independent channels, with LED and laser-photoemitters. 8 inputs, BF generator, miliammeter
• RECEIVER KIT: calibrated optic power meter
• principles of transmission through Fibre Optics
• latest tendencies like LASER and WDM systems



MODULATOR ASI-TS MPEG -> ISDB-T/TB PROMAX MO-370

• -T and ISDB-TB modulator contained in a 19" 1U chassis
• inputs can be used to modulate the COFDM signal
• TS MPEG INPUT: 2x ASI
• RF OUTPUT: 45-875 MHz (1 Hz steps), approx. 80 dBµV power



SPLICER FIBRA OPTICA PROMAX PROLITE-41

• Fibre aligning by means of Core aligning method
• Anti-shock protector
• FASTER splicing: 7 s splicing, 25 s heating
• Applicable fibers: SM, MM, DS and NZDS
• Higher resolution LCD with configurable screen orientation Replaceable Heating Unit
• Interchangeable fiber holders
• USB Port



TRANSMODULATOR DVB-S/S2 -> DVB-T PROMAX DT-232

• DVB-S/S2 FI INPUT: 2 independent DVB-S/S2 IF inputs
• RF OUTPUT: 2 independent combined DVB-T multiplexes
• interface for Conditional Access Module (CAM)
• PID Filtering Table up to 32 PID



ANALIZOR CATV RETEA CABLU TV PROMAX-4
