Multimetru portabil Izolat IP67 4.5 digit Fluke 28 II

Cod: Fluke 28-II




Brosura produs PDF, 1.82 Mb

Descriere

  • 4.5 digit
  • 20,000 count resolution for precise measurements
  • 0.05% basic accuracy
  • New - IP 67 waterproof & dustproof protection, completely sealed for use in
  • harsh environments
  • Peak min-max
  • True-rms ac voltage and current for accurate measurements on non linear
  • signals
  • Built in thermometer conveniently allows you to take temperature readings without having to carry a separate instrument
  • Measure up to 1000 V ac and dc
  • Measure up to 10 A (20 A for 30 seconds)
  • 10,000 µF capacitance range
  • Frequency to 200 kHz
  • Extended ac voltage bandwidth- 15 Hz to 20 kHz
  • Resistance, continuity and diode test
  • Min/Max and average recording to capture variations automatically
  • Unique function for accurate voltage and frequency measurements on adjustable speed motor drives and other electrically noisy equipment
  • Designed to withstand 3 meter drop (with holster)
  • New - Backlit keypad buttons allow for easy visibility in low-lit areas
  • Large display digits and 2 level bright white backlight for increased visibility
  • Reversible holster for added protection when not in use
  • Withstands hazardous 8,000 volt spikes caused by load switching and
  • faults on industrial circuits and complies with second edition IEC and ANSI
  • electrical safety standards
  • Long battery life (800 hours)
  • Relative mode to remove test lead resistance from low ohms measurements
  • Auto and manual ranging for maximum flexibility
  • Optional magnetic hanger for easy setup and viewing while freeing your
  • hands for other tasks
  • MSHA approval (pending)
