Embedded Based Home Network Trainer ED-5967

• Conversion processing experiments on the produced energy(power production / processing)
• Energy efficiency experiments followed by energy production and conversion
• Voltage and current characteristics curve
• Standalone or integrated operation of the energy experimental module
• Enriched teaching aids such as simulation software for power production



• Easy-to-use demonstarator for principles of refrigeration/airconditioning
• Motor Compressor : Pison type
• Trouble shooting for pipe leakage



• Load characteristics of DC compound motor
• Cumulative compound and differential compound characteristics
• Generator’s rotating speed and output characteristics
• Loss and efficiency of DC compound generator



• Mountable 5pieces MCU(8051,PIC, ATmega128, ATmega8535, upd78F0547)
• Practice of various communications such as RS-232 USB and Ethernet
• SoC experiments using the default FPGA (EP1C4F324)
• Storage of sensor data display and excel data using UI(LabVIEW)



• Computer-Integrated Manufacturing Training System under the application of advanced control technology for real field experiences
• Capable of "per unit" configuration into the two or more processes, or entire processes for customized experiments by combining each process



• Experiments on various types of special control unit
• Characteristics of Servo Motor and setup of Servo Driver
• Essential components in automation using a PLC position module
• 4mm banana jack to increase wiring capability



• Organization of various control elements in complexity for applied technology
• Total of 6 processes comprising supply, Sensor, Stopper, Absorption & Transfer, Conveyor and Loading
• Built-in control elements covering mechanics, electricity, and electronics
• Control circuit for simple and high speed data transmission in the USB type

• High-performance digital synthesizer method
• Wide Frequency Coverage : 9 kHz ~ 6.2 GHz
• Superior Resolution : Minimum 1 Hz
• Compact & Portable size
• Wide Input Dynamic Range : -105 ~ 20 dBm
• Various and Convenient Interfaces : USB, LAN



• 5 experimental modules for power electronics covering basic theory and applied experiments
• Capable of real-time measurements on PC by linking it to CBIS-1400 model
• By connecting PC to the Docking station, contact control is implemented on MMI(HMI) based software
• Report on experimental results & electronic manual on PC



• Disassembly and assembly practices for the robot actuators
• Utilization of a robot being used in the industry, so to apply a job site after graduation
• Simulation software provided to make assembly or disassembly easily
• Enables basic operation and testing practices on the assembled unit using a controller
