Installation, commissioning & servicing of industrial/commercial oil, gas or biomass appliances
Safety checks
- CO in a room or around an appliance
Combustion performance checks
Combustion efficiency checks
Flue Draught

Measures

O2 0-21%
CO 0-4,000ppm (hydrogen compensated)
Differential pressure
Temperature - inlet / flue gas / differential
* CO 0-100,000ppm
* NO 0-100ppm
* NO 0-5,000ppm
* NO2 0-1,000ppm
* SO2 0-100ppm
* SO2 0-5,000ppm
* Choose up to 2 additional sensors

Calculates

CO2
CO/CO2 ratio
Excess air
Combustion efficiency
* NOx (if NO sensor fitted)

Fuels Types

Natural Gas
Butane
Propane
LPG
28 sec oil
35 sec oil
Heavy oil
Solid fuel
User fuel

Accesorii standard

Box Contents

Analyser
Probe
Charger
Manual
Calibration report & carry case

Optiuni recomandate

Sensor Upgrades

KANE905 & KANE945 SO2 sensor (0-5,000ppm)

KANE905 & KANE945 High Range CO sensor (0-10%)

KANE905 & KANE945 NO sensor (0-5,000ppm)

KANE905 &KANE945 Low range NO sensor (0-100ppm)

KANE905 & KANE945 NO2 sensor (0-1,000ppm)
