Installation, commissioning & servicing of domestic / commercial oil, gas or biomass appliances
Safety checks
CO in a room or around an appliance
Combustion performance checks
Combustion efficiency checks
Flue Draught

Measures

CO2 direct with an infra-red sensor 0-20%
CO 0-10,000ppm
NO (High/Low optional upgrade)
Differential temperature
High accuracy differential pressure meter +/- 160mbar

Calculates

O2
CO/CO2 ratio
NOx (optional)
Excess air
Combustion efficiency

Fuels Types

Natural Gas
Butane
Propane
LPG
28 sec oil
35 sec oil
Wood pellets
User fuel x3

Box Contents

Analyser
Probe
Pressure connectors
Charger
Manual
Calibration report

Specification

May be subject to change

Parameter	Range	Resolution	Accuracy
Temp Measurement
Flue Temperature	0-600°C	0.1°C	±2.0°C ±0.3% reading
Inlet Temperature Internal Sensor	0-50°C	0.1°C	±2.0°C ±0.3% reading
Inlet Temperature External Sensor	0-600°C	0.1°C	±2.0°C ±0.3% reading
Flue Gas Measurement
Oxygen^*2	0-21%	0.1%	±0.3%
Carbon Monoxide^*1	0-20ppm 21-4,000ppm nom 4,001-10,000ppm 20,000ppm max for 15 mins	1ppm	±3ppm ±5% of reading ±10% of reading
Carbon Dioxide^*1	0-20%	0.1%	±0.3% volume
Efficiency (Net or Gross)^*2	0-99.9%	0.1%	±1.0% of reading
Efficiency High (C)^*2	0-119.9%	0.1%	±1.0% of reading
Excess Air^*2	0-250%	0.1%	±0.2% of reading
CO/CO₂ ratio^*2	0-0.999	0.0001	±5% of reading
** Pressure (differential)
Nominal range ±1600mbar	±1mbar	Maximum 0.001mbar	±0.05mbar
Maximum over range without damage to sensor is ±800mbar	±160mbar	< 25mbar	±3% of reading
Pre-programmed Fuels	Natural gas Propane Butane LPG Light Oils (28/35 sec) Wood Pellets plus 3 User Fuels
Storage Capacity	99 Combustion tests 20 Pressure tests 20 Tightness tests 20 Temperature tests 20 Room CO tests

^*1Using dry gases at STP
^*2Calculated


Ambient Operating Range	0°C to ±45°C - 10% to 90% RH non-condensing
Battery Type / Life	4 AA cells - > 8 hours using Alkaline AA cells
Chargers (optional)	220v charger, for NiMH batteries only
Dimensions
Weight:	0.8kg handset with protective cover
Handset:	200 x 45 x 90mm
Probe	300mm long including handle. 6mm diameter x 240mm long stainless steel shaft with 3m long neoprene hose. Type K thermocouple

Accesorii standard

Box Contents

Analyser
Probe
Pressure connectors
Charger
Manual
Calibration report
