Osciloscop analogic 2 x 200 MHz GW Instek GOS-6200

Cod: Good-Will Instek GOS-6200




Brosura produs PDF, 0.4 Mb

Descriere

  • 200MHz Bandwidth, Delayed Sweep
  • 2 analog channels
  • Built-in 6 Digits Counter
  • Cursor Readout with 7 Measurements
  • 10 Sets Memory for Front Panel Setting Save & Recall
  • TV-Line Selection (NTSC, PAL, SECAM)
  • Panel Setup Lock of Digital-Control Functions
  • Buzzer Alarm
  • Auto Set
  • LED Indicators


Accesorii standard

  • User manual x 1
  • Power cord x 1
  • GTP-250A: 250MHz Probe (10:1/1:1) Switchable Passive Probe (One per channel)


Optiuni recomandate

  • GTL-110  Test lead, BNC-BNC heads
  • GTC-001  Instrument cart, 450(W) x 430(D)mm (120V input socket)
  • GTC-002  Instrument cart, 330(W) x 430(D)mm (120V input socket)
