Esders VibraGAS Ex Tester gaz u certificare EX

• Taking the service box to the measurement site
• Activate device and connect sensor
• Feed sensor into sensor hole and start analysis at the touch of a button
• SAFE absorbs a gas sample and displays its concentration in vol.%
• The gas sample passes through the chromatographic column and the display of methane and ethane (if applicable) takes place



• Aparat de măsurare antiexplozie ATEX
• Se pot instala până la trei senzori de gaz (Ex/Ox/Tox)
• Dispozitivul poate fi echipat baterii Li-ion, pompă È™i măsurare presiuni
• compact, rezistent la explozii, pentru până la cinci gaze combustibile È™i toxice, precum È™i oxigen
• carcasă din plastic extrem de durabilă din 2 componente



• 2 month battery life on a single charge (infrared version)
• Compact and lightweight
• Low maintenance cost
• Simple to use
• LEL sensor (IR) does not require oxygen



• Improved sensor technology and adjustment options
• Increased operating temperature range of -20 to +50 ° C
• By up to 44% larger display area for better readability
• Red backlight for improved perception of alarm messages



• Easy replacement of batteries with innovative battery Management
• Systematic evaluation of the measured data using Esders PC-1 software
• Graphical printout on site on mobile printer
• Simple operation with intuitive menu navigation
• Practical accessories for all applications



• Operational life of two years
• Full factory warranty throughout the life of 24 months
• Measurement of H2S, CO and O2 ensures the safety of the worker
• Reduces training time
• Loud audible alarm, bright visual alarm, vibrating alarm



• Use of infrared sensors for CH4 and CO2 guarantee fast run-in period and extremely short response times and exclude cross-sensitivities to other gases.
• An oxygen and a hydrogen sulphide sensor are offered as an option.
• The measurement range for H2S is 0 to 2,000 ppm and cover the requirement for measurements at biogas plants ideal.



• The Esders Vakumobil has a markedly improved suction power compared to conventional technology.
• The low pressure in the surface generated by one suction probe has an impact over several metres.
• This creates only a movement or distortion of the gas accumulation but not there elimination.



• Usability test in accordance with G5952 or Esders express procedure
• Leak detection via external, digital hand sensor with integrated calibration and vibration alarm
• Automatic and manual test on controllers and safety valves
• Leak test with 150 mbar, strength test with 1 bar
• Pressure measurement up to 25 bar via external sensors



• Rugged hand-held instruments with ergonomic aluminum housing
• Wide range of applications in the gas installation
• Powerful gas detector with vibration alarm and digital display reading for gas leak detection
• High contrast LCD display with backlight for an optimal presentation of all measured values
