Portable Mitsubishi PLC Trainer ED-4260MP

• Modularized by each communicarion type
• PAM, PTM, PCM, DPCM, ADPCM, LDM, ADM, Delta-sigma
• No need to have additional generators (built-in power supply and signal source)
• Can display the test point and measure signals using an oscilloscope



• Aluminum hard case structure for mobility
• Applied experiments on the motor’s rotation characteristics
• AC motor control technology using the inverter
• Interlocking experiments with Programmable Logic Controller



• E/O and O/E conversion and characteristics
• Optical PCM communication(trasmission&reception)
• Optical Data communications using personal computer
• DC power supply, a roll of fiber cable and the microphone included as peripherals



• PC-based multi-function instrument for electricity/electronics and other experiments
• Digital Storage Oscilloscope with the 2-channel simultaneous 50MS/s sampling rate
• Spectrum Analyzer functions using Digital Storage Oscilloscope(DSO)
• Variable Power Supply(VPS), Function Generator(FG), Analog Output and Digital Output
• Analysis of collected data on PC through the modules of DSO, DMM, FC and Analog/Digital Input
• Numerical and graphical indication of the data measured and analyzed in real time



• Foundation for the Ubiquitous System Build
• Intel PXA 270 high performance processors
• 6.4TFT LCD, Ethernet 3Port, Serial 3Port, PCMCIA/CF/MMC interfaces
• FPGA Chip Altera Cyclone 4,000 LEs(12,000 LEs Option) for SoC courses
• Processor Core Board & CMOS Image Sensor



• Organization of various control elements in complexity for applied technology
• Total of 6 processes comprising supply, Sensor, Stopper, Absorption & Transfer, Conveyor and Loading
• Built-in control elements covering mechanics, electricity, and electronics
• Control circuit for simple and high speed data transmission in the USB type

• Fuel cell generation using photovoltaic
• Complete disassembly and assembly of the fuel cell
• Current and voltage measurement for PEM Fuel Cell Stack according to each of Cell
• Power production experiment using PEM Fuel cell



• Various types of circuit experiments with 17 basic modules plus 3 optional modules
• Main console(power supply) and storage cabinet



• Various types of test point for Air-interface experiments
• Anti-collision function
• OCX Library useful for application engineers
• 13.56MHz I-CODE Type in common usage
• Capability of reading and writing data on Tag



• Realistic Simulation of FM stereo broadcast
• Graphical layout of block diagrams, display elements and test points
• Covers the principles of FM stereo encoder and decoder
• Experiments on stereo amplifier (equalizer, tone control, pre-amp, etc.)
