Precise high frequency impedance measurements
Characterize components from 20Hz to 120 MHz
Wide range of models with maximum frequencies from 5MHz (6505P ) to 120MHz (65120P )
0.05% basic measurement accuracy
Comprehensive measurement functions
Easy to use with large TFT touch screen
Clear graphic displays aids measurements
Resonance Search
Intuitive user interface
Fully programmable over GPIB and LAN
Keyboard and mouse optional control
Competitively priced

Accesorii standard

User Manual
AC power cord
1J1011 Fixture
USB memory
Pen/stylus
Calibration Certificate

Optiuni recomandate

Options
Bin handler		/B1
Bin handler ( isolated 24V )		/B2
DC Bias ( 0 to +100mA and 0 to +40V )		/D1
DC Bias ( -40V to +40V )		/D2

Optional Accessories
Surface Mount Fixture ( 2 Terminal )		1J1012
Surface Mount Fixture ( 4 Terminal )		1J1014
Certificate of Calibration with results		1JCALRES
