MPEG-2 Transport Stream Recorder, Processor, Player Promax TG-140

Cod: Promax TG-140




Brosura produs PDF, 0.16 Mb

Descriere

The TG-140 is a versatile MPEG-2 transport stream recorder and player that can be used in a great number of applications. It can record a transport stream continuously for several hours (up to 15 hours at 20 Mbps) and then play it back later on at pleasure. Its recording capacity can be also split in plenty of shorter duration transport streams.





INPUTS

ASI transport stream
Maximum data rate 150 Mbps

OUTPUTS

ASI transport stream
SPI parallel transport stream
Maximum data rate 90 Mbps

STORAGE CAPACITY

Hard disk 160 GB
15 hours of 20 Mb/s transport stream

PC CONNECTION

USB interface
Ethernet interface
