Multimetru portabil de uz general Metrel MD 9020

• Voltage: TRMS, peak, crest factor (4-channel)
• Current: TRMS, peak, crest factor (4-channel)
• Power (active, reactive, apparent)
• Power measurements fully compliant with IEEE 1459 (active, nonactive, fundamental, harmonic, load unbalance)
• Unbalance, flicker measurement
• Harmonic and interharmonic analysis up to 50th harmonics, THD measurement
• Energy (active, reactive, generated, consumed)
• Power quality analysis according to EN 50160 and IEC 61000-4-30 Class A



• Wiring check
• DC insulation resistance
• Continuity test
• Line and Loop resistance
• RCD test
• Phase sequence
• Pass/Fail visual and audio presentation of results



• Voltage testing up to 1000 V
• Automatic AC/DC recognition
• Continuity buzzer and led to indicate resistances below 500 k?
• Phase & Rotating Field Test
• RCD trip testing
• Diode Test
• Auto Power Off



• Field proven instrument for under-wall low voltage installation tracing
• fuse finding
• short-circuit spot determination and metal installation tracing
• Can be used on energized or voltage-free systems.
• Tips and detailed descriptions of connection schemes for various combinations from everyday practice.



• 1000V AC, DC voltage measurement;
• 8A AC, DC current measurement;
• 600O..60MO Resistance measurement;
• 60nF..3mF Capacitance measurement;
• 5Hz..1MHz Frequency Measurement
• Temperature measurement(thermocouple type K included)



• Bidirectional resistance measurement from 0,1 µO up to 2000 O
• test current up to 10 A
• Highly efficient 10 A current source generates 10 A into 200 mO load for 15 min without overheating
• High overvoltage protection (CAT IV / 300 V)
• Custom limits can be set for PASS / FAIL evaluation of test result.
• 50 Hz / 60 Hz ripple detection and rejection.
• Instrument can be powered from mains or internal rechargeable battery.
• Up to 1000 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• Bidirectional resistance measurement from 1 µO up to 199,9 O
• test current up to 2 A
• High overvoltage protection (CAT III / 600 V)
• Internal protection cicuit
• 50 Hz / 60 Hz ripple detection and rejection.
• more than 800 measurements of 500 mO load 8 2 A test current & 15 s measurement duration
• Pre-programmed limits with PASS/FAIL evaluation of measurement result
• Up to 1500 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• Both IP (inductive) & IG (contact) RPM;
• ms Fuel-injection on time;
• % Duty cycle;
• Dwell angle;
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 6uF..2mF Capacitance measurement;
• 600O..60MO Resistance measurement;
• Electric field detection;
• Temperature measurement(thermocouple type K included)



• CAT IV/1000 V overvoltage category
• 1000V TRMS AC, DC voltage measurement;
• 10A TRMS AC, DC current measurement;
• 60nF..25mF Capacitance measurement;
• 600O..60MO Resistance measurement;
• Diode test;
• 5Hz..1MHz Frequency of digital signals measurement



• IT System recognizing, Voltage Range and Voltage Balance;
• ISFL Single Fault Leakage current from Phase 1 and Phase 2 to PE;
• Fuse Trip-out Ability Evaluation, Line Impedance and Ipsc Prospective Short Circuit Current;
• IMD Insulation / ELM Earth Leakage / RCM Residual Current Monitor Devices Control;
• Alarm Trigger or Trip-Out Check and Adjust.
