Analizor audio clasa 1 HT Italia HT155/ HT157

• Izolaţie cu tensiune de 50, 100, 250, 500, 1000VDC
• Analiza calităţii energiei şi a consumului de energie trifazat
• Se pot înregistra 632 de parametri timp de peste două luni
• Diagramă vectorială tensiune/curent
• Forme de undă tensiune/curent
• Tabele sau histograme de armonici şi THD%
• Conexiune WiFi integrată şi compatibilitate cu aplicaţia HTANALYSIS



• DC, AC + DC TRMS current up to 1000A
• DC, AC + DC TRMS voltage up to 1000V
• Resistance and continuity test
• Active, Reactive, Apparent power on Single/Three phase systems
• Active, Reactive energy on Single/Three phase systems
• Power Factor on Single/Three phase systems
• Harmonic voltage/current up to 25th with THD% calculation
• PC connection via Bluetooth



• TRMS AC Voltage measure up to 600V
• Recording with sampling programmable period
• Manual activation of recording
• RS-232 interface
• Programming with DATALINK software



• Măsurători IEC/EN60204-1 si IEC/EN61439-1-2
• Continuitatea circuitului de protecţie cu 200mA
• Continuitatea circuitului de protecţie cu I>10A, V<12V
• Continuitatea circuitului de protecţie cu I>25A, V<12V
• Izolaţie cu tensiuni de testare 100, 250, 500, 1000VDC
• Rigiditate dielectrică cu tensiune programabilă de la 250V la 5100VAC



• Insulation measurement up to 1,500V DC even on live systems
• Localization of the faulty module through the new GFL function
• Continuity of the protective conductor with 200mA



• Safety test of PV installation
• Continuity test on protective conductors with 200mA
• Insulation test with test voltage of 250, 500, 1000VDC
• DC voltage
• DC current
• DC Power
• Solar irradiation [W/m2] with reference cell



• Trasarea curbei I-V a modulelor şi şirurilor fotovoltaice monofaciale şi bifaciale de până la 1500V/40A conform IEC/EN60891
• Unitate de la distanţă SOLAR03 cu conexiune Bluetooth
• Până la 3 celule de referinţă pentru măsurarea radiaţiei frontale şi posterioare conform IEC TS 60904-1-2
• Bază de date cu peste 30.000 de module fotovoltaice gestionabile prin conexiune cu noul software HT AGORÀ (descărcabil în Zona de Descărcări)



• Measuring range 25-140dB
• "Peak", "Fast", "Slow" and "Impulse" integrations
• "A", "C" and "Z (linear)" frequency weighting
• "Peak+" and "Peak-" measurement in C weighting
• Spectral analysis with octave and 1/3 octave digital filter (HT157)
• Class 1 portable calibrator
• Mini-USB output for connection to PC



• TRMS
• Tensiune AC/DC 1000V, inclusiv AC+DC
• Curent AC/DC 1A, inclusiv AC+DC
• Măsurare curent DC 4-20mA
• Măsurare tensiune DC 0-10V
• Generare curent DC 4-20mA
• Măsurare curent de ieșire al traductoarelor
• Simulare a unui traductor extern



• Insulation Resistance with 250, 500VDC
• Measurement range up to 1GOhm
• Automatic discharging object after test
• Continuity test of protective conductors with 200mA
• DC Voltage
• AC TRMS Voltage
