Telecommunication Trainer ED-2960

• Foundation for the Ubiquitous System Build
• Intel PXA 270 high performance processors
• 6.4TFT LCD, Ethernet 3Port, Serial 3Port, PCMCIA/CF/MMC interfaces
• FPGA Chip Altera Cyclone 4,000 LEs(12,000 LEs Option) for SoC courses
• Processor Core Board & CMOS Image Sensor



• 15 experimental modules for basic electricity/electronics and analog & digital circuits
• Capable of real time measurement on PC by linking it to CBIS-1400 model.
• By connecting PC to the Docking station, contact control is implemented on MMI(HMI) based software
• Report on experimental results & electronic manual on PC



• Comprehension of basic production automation processes such as transfer, fabrication, classification, inspection and storage
• Convenient wiring and pipe arrangement with a label of each component such as sensors and actuators
• PLC training system function(various types of sequence actions through a change in PLC control program
• Counter/timer function and motor control by PLC or without PLC(electrical method)
• Aluminum profile worktable & control modules for easy mounting



• Organization of various control elements in complexity for applied technology
• Total of 6 processes comprising supply, Sensor, Stopper, Absorption & Transfer, Conveyor and Loading
• Built-in control elements covering mechanics, electricity, and electronics
• Control circuit for simple and high speed data transmission in the USB type

• Conversion processing experiments on the produced energy(power production / processing)
• Energy efficiency experiments followed by energy production and conversion
• Voltage and current characteristics curve
• Standalone or integrated operation of the energy experimental module
• Enriched teaching aids such as simulation software for power production



• Panel type structure for good grasp of entire network configuration
• Learning about the functions and characteristics of basic network equipments such as NIC, HUB, Router and DSU, plus installation and maintenance
• Interlocking experiments with Internet for clear understanding a real network
• Capable of conneting to the open network on campus



• Belt-type conveyor simulator
• Control Modes : manual or automatic by programmable Logic Controller
• Three photo sensors and two motion solenoids



• Experiments on various types of special control unit
• Characteristics of Servo Motor and setup of Servo Driver
• Essential components in automation using a PLC position module
• 4mm banana jack to increase wiring capability



• PLL and Digital Synthesizer
• PAM, PCM, FDM and FSK Modem
• 10types of module including DC Power Supply



• Unique logic cards(TTL/CMOS)
• Internal pulse outputs
• 3-stage Logic Monitor
• BCD indication
