Deviser AE600 CWDM Channel Analyzer

• Perform comprehensive spectrum and signal analysis for complete site profile and monitoring of signal environment
• Test MIMO 4x4 antenna performance
• Detect signal degradation and system performance over time with trace overlay



• Compatible with DVB-T/T2 and DVB-C standard
• DVB-T/T2: Comply with ETS300744 standard/ Support Power, MER, CBER and VBER
• DVB-C: Support Digital and Analog TV Measurements
• Spectrum Function (5~1000MHz)
• Easy to use



• 1310/1550 nm Wavelength
• Up to 40dB dynamic Range
• 6.4” color TFT LCD display for improved viewing.
• Friendly operation interface and convenient one-button testing.
• High-speed signal processing, less measurement time, and faster result analysis.
• Ideal for the field: compact and lightweight, shock proof, water proof, resistant to dust and common chemicals.
• Large internal memory (up to 1000 test results).
• Lithium battery included with more than 10 hours operation time.
• Based on Linux operating system and unlimited upgrade.



• 1U rack spectrum analyzer for remote head end monitoring
• 1 ~ 1000 MHz frequency span
• LAN connection
• Same performance as DS8831Q
• Workbench remote control software
• Cost-effective to modify network configuration
• Full 1 GHz performance RF matrix 16 x 1
• Units can be daisy chained to support up to 256 inputs



• Frequency Range 300KHz~1.3GHz
• 75 or 50 ohm
• Two channels, Four traces display
• Logarithm amplitude, Linearity amplitude, Phase, Group delay, Real part, Imaginary part
• Smith chart, Pole chart
• Transmission, Insertion Loss, Gain, Insertion Phase, Isolation
• Return Loss, VSWR, Impedance
• USB, parallel, RS-232 and VGA,LAN interface



• Analyze 18 wavelengths (ranging from 1271 ~ 1611nm) simultaneously
• All-day testing with 5 hours' continuous operation
• With interchangeable connectors, switch easily among FC / SC / LC / ST
• View measurement results in list or graph format
• Store up to 1000 data groups; manage them with Toolbox PC software



• Detect signal degradation and system performance over time with trace overlay
• Instant Pass/Fail status
• Manage your measurement data and test setups with Measurement Center Software
• Intuitive touchscreen user interface for easier, faster measurements



• mainly applied for the installation of data service of HFC Network
• compatible with DOCSIS & Euro DOCSIS 1.1/2.0/3.0
• simple measurement of Analog TV, DVB-C and Spectrum
• 3.5 Inch TFT LCD
• USB storage and upgrade
• Toolbox - PC Management Software



• 1000Base-X optical port x 1, 10/100/1000Base-T electric port x 1
• Complete solution for activating, verifying & fault-diagnosing Ethernet service from 10Mbit/s to 1Gbit/s quickly and easily
• Convenient and intuitive user interface
• Integrates multiple software tools for field measurement, ensuring high cost-performance
• Professional PDF and CSV data report generation



• 20 MHz / 40 MHz Output Frequency
• Frequency Output simultaneity
• Output level is adjustable.
• Small dimension,light weight
