Deviser DS2580C Digital TV QAM Analyzer

Cod: Deviser DS2580C




Brosura produs PDF, 1.54 Mb

Descriere

Integrating multiple functions in a single handheld instrument, the new DS2580C is a powerful Digital TV QAM Analyzer with a comprehensive measurement suite specifically designed for HFC network testing, troubleshooting, and maintenance. The DS2580C's main functions include Enhanced Spectrum Analysis, Analog & Digital TV analysis, DOCSIS 3.0 analysis, Upstream Signal Generator, Ethernet testing, and Auto Test. The revolutionary EVS function enables users to detect coherent distortions hiding under QAM carriers - without interrupting service. The DS2580C supports Deviser's PC software toolkit, included with each unit, to make data transfer a snap.



Features:

  • High Speed Spectrum Analysis: 4~1000MHz
  • Integrated DOCSIS 3.0 Cable Modem
  • Integrated Upstream Signal Generator (no FEC)
  • Supports ITU- -T J.83 Annex A/B/C
  • Error Vector Spectrum: identifies interference signals under QAM carriers, with no break in service
  • Auto Test
