Deviser TC601+ Ethernet Service Tester

• Analog TV Analysis: Level, Tilt, C/N, Scan and Trunk Voltage
• Digital TV Analysis: Power Level, MER and BER
• 128½64 backlit LCD screen
• Li-ion battery provides >4 hrs. operation
• Upgrade software and edit channel plans easily via USB interface



• Broad dynamic range coverage (28 - 39 dB)
• Minimum 5cm resolution
• Intelligent analysis of events
• Excellent stability and repeatability



• E7000A: 25 MHz to 4400 MHz
• E7100A: 25 MHz to 6000 MHz
• Spectrum Analyzer Option 100kHz to 3000 MHz
• Return Loss/VSWR
• Cable Loss
• Distance-To-Fault
• 1-Port Phase
• Smith Chart
• 2-ports Transmission Measurements(With E7000-SA Option)
• USB Power Meter Sensor Option
• GPS Receiver Option



• Perform comprehensive spectrum and signal analysis for complete site profile and monitoring of signal environment
• Test MIMO 4x4 antenna performance
• Detect signal degradation and system performance over time with trace overlay



• 850nm, 980nm, 1300nm, 1310nm, 1490nm, 1550nm, 1610nm Wavelengths
• 0.01 dBm Resolution
• fber network installation, debugging and maintenance in optical network, CATV and FTTX field
• Up to 50 hours working time with 3 5AA rechargeable batteries
• Visual Fault Locator
• Auto shutdown and self-calibration function
• USB Interface and toolbox software



• Quickly identifies, locates and maps signal interference
• Performs comprehensive signal analysis for complete site profile and monitoring of signal environment
• Occupied Bandwidth, Channel Power and ACPR
• Dual spectrum and spectrogram measurements
• Verify RF transmission



• Frequency Range 300KHz~3GHz
• 75 or 50 ohm
• Two channels, Four traces display
• Transmission, Insertion Loss, Gain, Insertion Phase, Isolation
• Group Delay, Return Loss, VSWR, Impedance
• USB, parallel, RS-232 and VGA,LAN interface



• 1310/1550 nm Wavelength
• Up to 40dB dynamic Range
• 6.4" color TFT LCD display for improved viewing.
• Friendly operation interface and convenient one-button testing.
• High-speed signal processing, less measurement time, and faster result analysis.
• Ideal for the field: compact and lightweight, shock proof, water proof, resistant to dust and common chemicals.
• Large internal memory (up to 1000 test results).
• Lithium battery included with more than 10 hours operation time.
• Based on Linux operating system and unlimited upgrade.



• 1 MHz.. 1 GHz Frequency Range
• 50 or 75 ohm input impedance
• Design QAM analysis, spectrum analysis and CATV analysis in one unit
• QAM analysis: MER, BER, EVM, Constellation Diagram etc
• Support QAM/ITU-T J.83 ANNEX A/B/C/D and QPSK, COFDM
• CATV analysis
• Battery and AC power supply



• 1310/1550 nm Wavelength
• Up to 36dB dynamic Range
• High Accuracy
• Fast Test
• Easy Operation
• Small Size and ideal for field
• Long Working Time
