PCI Board 8-Analog + 32 Digital Output Keithley KPCI-3130

• Five instruments in one (IV Source, IVR Measure)
• Six models: 20 - 100W DC, 1000W pulsed, 1100V to 1uV, 10A to 10pA
• Source and sink (4-quadrant) operation
• 0.012% basic measure accuracy with 5½-digit resolution



• 96 or 24 TTL-level compatible digital I/O lines
• Bi-directional I/O
• High-current driver capability, 15mA (source) and 64mA (sink)



• 32 optically isolated solid-state relays and digital inputs
• Direct, non-polarized switching and sensing: DC up to 60VDC, AC up to 30Vrms
• High load current capability up to 350mA



• 16-bit resolution
• Input speeds of up to 250kS/s
• Output speeds of up to 200kS/s
• Digital I/O scanning speeds of up to 3MHz
• 32 single-ended or 16 differential analog inputs
• 16 digital I/O lines
• 2 analog outputs, waveform quality, 200kS/s



• 1 mHz - 165 MHz frequency output range
• 2 channels
• 3 ns - 1000 s pulse width range
• 10 V amplitude into 50 O, 20 V into 1 k O



• Dual-channel instrument for optical power measurements, beam measurements, and nanoscale materials and device research
• ±100V source for bias requirements
• Measure photodetector current from 1fA to 20mA
• 1fA current measurement resolution



• 7.5 digit resolution
• 100nV rms noise floor
• 7ppm DCV repeatability



• 0.4 fA p-p (4E - 16 A) noise
• Remote PreAmp can be located at the signal source to minimize cable noise
• Up to 6½-digit resolution



• Make low noise measurements at high speeds
• typically just 15 nV p-p noise at 1s response time
• 40..50 nV p-p noise at 60ms



• 6.5 digit DMM
• THD, THD+Noise and SINAD measurements
• 20Hz-20kHz sine wave generator
• 9.5Vrms single-ended or 19Vrms differential output
• Identifies peak spectral components(2016-P model)
