3, 4 or 6 power phases
FFT analysis, vector diagram, and Digital Oscilloscope (DSO) mode included in the base Voltage, current and power harmonics measured up to the 40th harmonic for complete analysis
unit for complete analysis capability
Compact design makes it easy to carry and saves working space
Simple user interface ensures easy, intuitive operation
A variety of standard configurations allows users to choose the exact functionality required for their unique application
Simultaneous parallel acquisition of all phases allows accurate viewing of dynamic events on all phases at exactly the same point in time
All inputs are galvanically isolated to avoid short circuits in all applications
User-selectable average time - from 15ms up to 3600s - for dynamic measurements
4 MB on-board memory (expandable to 128 MB) for storage of measured values
Fast and easy connection to a PC - RS232 and USB included as standard; optional IEEE488, Ethernet, or USB2.0
PI1 process interface to measure torque and speed with external sensors, plus four analog outputs for easy use on motor and drive applications
341kHz or 1 MHz sample rates for detailed signal analysis
Bandwidth from dc to 3 MHz / 10 MHz for reliable measurement precision
Fluke NormaView PC software for data download, analysis & report writing

Standard accessories

Power supply cable
5.7" / 144 mm color display
Internal printer
RS232/USB interface for data download
Space for six power-phases and options
Fluke NormaView PC software
User’s manual
Test certificate
Calibration values

Recommended options

Fluke-N5K 3PP50

Fluke-Norma 5000, three phase with 3xPP50 power phase input modules

Fluke-N5K 3PP50I

Fluke-Norma 5000, three phase with 3xPP50 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 3PP50IP

Fluke-Norma 5000, three phase with 3xPP50 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 3PP54

Fluke-Norma 5000, three phase with 3xPP54 power phase input modules

Fluke-N5K 3PP54I

Fluke-Norma 5000, three phase with 3xPP54 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 3PP54R

Fluke-Norma 5000, three phase with 3xPP54 power phase input modules and printer

Fluke-N5K 3PP54IP

Fluke-Norma 5000, three phase with 3xPP54 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 3PP54IR

Fluke-Norma 5000, three phase with 3xPP54 power phase input modules with IEEE488 / Ethernet interface and printer

Fluke-N5K 3PP64

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules

Fluke-N5K 3PP64I

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 3PP64IP

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 3PP64R

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules and printer

Fluke-N5K 3PP64IR

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules with IEEE488 / Ethernet interface and printer

Fluke-N5K 3PP64IPR

Fluke-Norma 5000, three phase with 3xPP64 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels and printer

Fluke-N5K 4PP54

Fluke-Norma 5000, three phase with 4xPP54 power phase input modules

Fluke-N5K 4PP54IP

Fluke-Norma 5000, three phase with 4xPP54 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 6PP42IB

Fluke-Norma 5000, three phase with 6xPP42 power phase input modules with current binding post with IEEE488 / Ethernet interface

Fluke-N5K 6PP42IBR

Fluke-Norma 5000, three phase with 6xPP42 power phase input modules with current binding post with IEEE488 / Ethernet interface and printer

Fluke-N5K 6PP50IP

Fluke-Norma 5000, three phase with 6xPP50 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 6PP50IR

Fluke-Norma 5000, three phase with 6xPP50 power phase input modules with IEEE488 / Ethernet interface and printer

Fluke-N5K 6PP50IPR

Fluke-Norma 5000, three phase with 6xPP50 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels and printer

Fluke-N5K 6PP50I

Fluke-Norma 5000, three phase with 6xPP50 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 6PP54I

Fluke-Norma 5000, three phase with 6xPP54 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 6PP54IP

Fluke-Norma 5000, three phase with 6xPP54 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 6PP54IR

Fluke-Norma 5000, three phase with 6xPP54 power phase input modules with IEEE488 / Ethernet interface and printer

Fluke-N5K 6PP54IPR

Fluke-Norma 5000, three phase with 6xPP54 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels and printer

Fluke-N5K 6PP64I

Fluke-Norma 5000, three phase with 6xPP64 power phase input modules with IEEE488 / Ethernet interface

Fluke-N5K 6PP64IP

Fluke-Norma 5000, three phase with 6xPP64 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels

Fluke-N5K 6PP64IR

Fluke-Norma 5000, three phase with 6xPP64 power phase input modules with IEEE488 / Ethernet interface and printer

Fluke-N5K 6PP64IPR

Fluke-Norma 5000, three phase with 6xPP64 power phase input modules with IEEE488 / Ethernet interface and analog / digital output channels and printer
