MPEG-2 Transport Stream Recorder, Processor, Player Promax TG-130

• MODULATIONS: AM, FM, PWM, FDM
• INPUTS / OUTPUTS: Generator, microphone / Oscilloscope, headphones
• TRANSMISSION: Two-wire, coaxial, Fibre Optics, Infra Red & Radio



• down converter for the 2.4 to 2.5 GHz to 1483 to 1583 MHz
• Converts signals from ISM 2.4 GHz to IF satellite band
• Supply from the signal level meter



• incorporated fault simulator module permits to practice units diagnosis and repairing methods
• designed from a stereo radio tuner equipped with the RDS system
• most advanced reception circuits



• WAVELENGTH RANGE : 1250 - 1650 nm
• SPAN RANGE: 10 nm - 400 nm
• RESOLUTION: 0.15 nm
• INPUT RANGE: -60 dBm to 10 dBm
• 3 HOURS AUTONOMY



• FREQUENCY MARGIN: From 50 MHz (C-2) to 860 MHz (C-69)
• INPUTS: 4 inputs Female BNC, 75 ? impedance
• RF OUTPUT: 1 female BNC output, 75 ? impedance
• output designed to mix output RF signals of COFDM modulators and transmodulators with DTT channels



• PAL B, G, H, D, K, I, M, N, NTSC M, SECAM B, G, H, D, K, K1, I, L TV Standards
• 4:3 and 16:9 format patterns
• NICAM and Zweiton Sound
• Addition of an electronic circle on all patterns (except colour bars)
• Two logotypes
• RS-232 remote control



• INPUTS FOR EACH COMBINER: 4 BNC female inputs 75 ? (16 total)
• OUTPUTS FOR EACH COMBINER: 1 BNC female output 75 ? (4 total)
• allows many different combinations to adapt to the needs of each system as best as possible
• used to mix the output RF signals of the COFDM modulators and transmodulators
• preserves better the original quality and maintains lower noise levels



• integrated DVB-T tuner that allows the TS capture in real time
• record a transport stream continuously for several minutes and then play it back
• work in the field where maybe it is not possible to find electricity available
• ASI Transport Stream Input: Maximum data rate 40 Mb/s
• RF Input: DVB-T from 35 to 100 dBµV
• ASI & SPI parallel Transport Stream Output: Maximum data rate 32 Mb/s
• Storing Capacity: Memory card 4 GB, 20 minutes approx (20 Mbits/s)



• DVB-T (DTT) output
• converts analogue/ digital video source to DVB-T with a max 200 programmes in the UHF band
• transmodulate Satellite TV channels to Digital Terrestrial Television multiplexes
• system allows to re-organise the spectrum, adding the off-air DTT channels received in the region
• encoding video-audio channels
• remotely controlled through Ethernet



• MPEG-2 TS INPUT: 2x DVB-ASI, 1x DVB-SPI
• IF OUTPUT: Fixed at 36 MHz
• RF OUTPUT: 475-875 MHz (45-875 MHz for MO-161 model)
• CONSTELLATIONS: QPSK, 16QAM, 64QAM
