Megohmmetru izolatie 10kV Metrel MI 3200 TERAOHM

• Insulation resistance up to 100 GO with DC voltage up to 2.5 kV;
• PI, DAR calculation;
• Continuity of PE conductors with 200 mA test current and polarity change;
• Continuity of PE conductors with 7 mA test current (continuous measurement) without RCD tripping;
• TRMS voltage and frequency.



• Wiring check
• DC insulation resistance
• Continuity test
• Line and Loop resistance
• RCD test
• Phase sequence
• Pass/Fail visual and audio presentation of results



• Bidirectional resistance measurement from 0,1 µO up to 2000 O
• test current up to 10 A
• Highly efficient 10 A current source generates 10 A into 200 mO load for 15 min without overheating
• High overvoltage protection (CAT IV / 300 V)
• Custom limits can be set for PASS / FAIL evaluation of test result.
• 50 Hz / 60 Hz ripple detection and rejection.
• Instrument can be powered from mains or internal rechargeable battery.
• Up to 1000 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• Voltage: TRMS, peak, crest factor (4-channel)
• Current: TRMS, peak, crest factor (4-channel)
• Power (active, reactive, apparent)
• Power measurements fully compliant with IEEE 1459 (active, nonactive, fundamental, harmonic, load unbalance)
• Unbalance, flicker measurement
• Harmonic and interharmonic analysis up to 50th harmonics, THD measurement
• Energy (active, reactive, generated, consumed)
• Power quality analysis according to EN 50160 and IEC 61000-4-30 Class A



• Simulation of common electrical installation usually met in an individual house or apartment
• Various test methods supported by different test instruments can be presented.
• Acceptable or faulty parameters can be preset by five »fault« switches.
• Some real elements of electrical installation are placed on the front panel like RCD protection device, ON/OFF switch



• Bidirectional resistance measurement from 1 µO up to 199,9 O
• test current up to 2 A
• High overvoltage protection (CAT III / 600 V)
• Internal protection cicuit
• 50 Hz / 60 Hz ripple detection and rejection.
• more than 800 measurements of 500 mO load 8 2 A test current & 15 s measurement duration
• Pre-programmed limits with PASS/FAIL evaluation of measurement result
• Up to 1500 test results with timestamp can be stored in internal memory.
• PC SW HVLink PRO enables downloading, review, analyses and printing of test results.



• DC and TRMS AC voltage up to 600 V
• TRMS AC current measurement up to 1000 A
• Resistance measurement
• Continuity test
• Frequency measurement
• Contact temperature measurement
• Power factor
• Power (W, VA, Var)



• Insulation resistance with DC voltage
• Continuity of PE conductors with 200 mA test current with polarity change
• Continuity of PE conductors with 7 mA test current (continuous measurement) without RCD tripping
• Line impedance
• Loop impedance
• Loop impedance with Trip Lock RCD function
• TRMS voltage and frequency
• Phase sequence
• RCD testing (general and selective, type AC, A and B)
• Earth resistance (3-wire method).



• Measurements on DC side of PV installation:
• Voltage, current, power, energy;
• Uoc (Open Circuit Voltage) and Isc (Short Circuit Current);
• I - U curve of PV modules and strings;
• Irradiance;
• Module temperature.
• Measurements on AC side of PV installation (power quality):
• Voltage, current, frequency, power, PF, energy, harmonics;
• Efficiency of PV module, inverter, PV system calculation.



• TRMS voltage and frequency
• Continuity
• Insulation resistance
• RCD testing (type AC and A)
• Fault loop / RCD Trip Lock impedance
• Line impedance
• Phase sequence
