Modul multifunctional I/O Agilent 34907A

• RF switching to 3 GHz
• Quad 1x4 50 ohm RF switch multiplexer to 3GHz
• 30V, 1A, 1W switching
• 50 dB isolation at 1 GHz
• 1.3 dB insertion loss at 3 GHz



• 8-Slot mainframe
• integrated 6.5 digit DMM
• 19 Plug-in modules - DC to 20 GHz switching
• Digital I/O
• D/A Converter
• Counter/Totalizer
• Standard LAN, USB, GPIB connectivity



• 500 MHz bandwidth
• 4 GSa/s sample rate
• 2 analog channels
• Standard 8 Mpts MegaZoom III deep memory



• 0.1% basic accuracy
• 100 Hz, 120 Hz, 1 kHz, 10 kHz, 20 kHz, 100 kHz test frequencies
• Measurement parameters: Z, Y, Theta, R, X, G, B, C, L, D, Q, Rdc, N, M



• 6½ digit resolution
• 1 Rack Unit size LXI Class C compliant (LAN, USB & GPIB standard)
• 50,000 readings/sec. @ 4½ digits to the PC



• 68-channel portable logic analyzer
• 48-channel pattern generator
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth



• 2 x 30 MHz sine, square, and pulse bandwidth cover more applications
• 250 MSa/s, 16-bit sampling rate for higher time-resolution arbitrary waveforms
• Dual-channel model with independent or coupled channels



• 70 2-wire channels
• Mixed 2- or 4-wire configurations
• High-speed reed relays, with relay counter



• 100 kHz to 1 GHz, 3 GHz or 6 GHz
• 0.01 Hz resolution
• +23 dBm output power @ 1 GHz
• AM, FM, ØM, and pulse modulation



• 68-channel portable logic analyzer
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth
