Mili Ohmmetru 1 kHz Agilent 4338B

• 136-channel portable logic analyzer
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth



• High speed USB 2.0 (480MBit/s)
• 16-bit resolution
• simultaneous analog input channels
• up to 250 kSa/s/ch
• 2 12-bit analog output channels
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 1 µHz - 330 MHz pulse generation with variable rise/fall time
• 1 µHz - 500 MHz sine waveform output
• 14-bit, 2.5 GSa/s arbitrary waveforms
• 1 or 2 channel, coupled and uncoupled



• Hi-Speed USB 2.0 (480 Mbps)
• 64 Input opto-isolated lines
• Functions as standalone or modular unit
• Up to 1250 Vrms isolation protection



• Two SPDT terminated switches
• 4 GHz, 20 GHz, or 26.6 GHz options
• High isolation, low VSWR
• Up to 50W switching



• 100 kHz to 1 GHz, 3 GHz or 6 GHz
• 0.01 Hz resolution
• +23 dBm output power @ 1 GHz
• AM, FM, ØM, and pulse modulation



• 100 MHz bandwidth
• 2 analog channels plus 8 digital channels
• 1GSa/s per channel sample rate



• 250 kHz to 20 GHz, 31.8 GHz, 40 GHz, 50 GHz or 67 GHz operational to 70 GHz
• 0.001 Hz resolution
• +23 dBm @ 20 GHz, +17dBm @ 40 GHz, +14 dBm @ 67 GHz output power (typ); > +30 dBm (typ) with Option 521.
• AM, FM, ØM, pulse, and scan
• Extendable to 75, 90, 110, 140, 170, 220, 325, or 500 GHz



• 64 Form A channels up to 1A, 50W
• Latching armature relays, with relay cycle counter
• Temperature sensor for overheating conditions



• 68-channel portable logic analyzer
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth
