Powermetru fibra optica Deviser AE100

• High Speed Spectrum Analysis: 4~1000MHz
• Integrated DOCSIS 3.0 Cable Modem
• Integrated Upstream Signal Generator (no FEC)



• 1 MHz.. 1 GHz Frequency Range
• 50 or 75 ohm input impedance
• Design QAM analysis, spectrum analysis and CATV analysis in one unit
• QAM analysis: MER, BER, EVM, Constellation Diagram etc
• Support QAM/ITU-T J.83 ANNEX A/B/C/D and QPSK, COFDM
• CATV analysis
• Battery and AC power supply



• Integration of optical power meter, light source and visible faulty locator
• FTTX application and PON wavelength
• 30 hours working time



• Analog TV measurements include: Level, V/A, HUM, C/N
• Auto-generates and saves up to 20 custom channel plans from a cable drop
• Auto test with pass/fail limits speeds up tests and simplifies results interpretation



• Designed for Ethernet systems
• Contains a main unit and a remote unit
• measures the speed and performance on CAT3, CAT5e and CAT6 cables
• according to ANSI/TIA/EIA-568-B and ISO/IEC 11801 to ensure the cable qualification
• Tone generator
• Two additional functions: Ping and BER Test
• Store at least 100 results
• Toolbox software to analyze the results on PC



• 1310/1550 nm Wavelength
• Up to 40dB dynamic Range
• 6.4" color TFT LCD display for improved viewing.
• Friendly operation interface and convenient one-button testing.
• High-speed signal processing, less measurement time, and faster result analysis.
• Ideal for the field: compact and lightweight, shock proof, water proof, resistant to dust and common chemicals.
• Large internal memory (up to 1000 test results).
• Lithium battery included with more than 10 hours operation time.
• Based on Linux operating system and unlimited upgrade.



• Analyze 8 CWDM channels simultaneously
• All day testing with field replaceable batteries
• Create test profiles for general functions such as relative power measurement
• Store up to 400 groups of data, and manage results with Toolbox management software



• light source qualified in optical network, CATV and FTTX maintenance
• Multi wavelength output,
• CW mode or modulated mode, 270Hz, 330Hz, 1KHz, 2KHz
• Adjustable output power
• 30 hours working time



• Analyze 18 wavelengths (ranging from 1271 ~ 1611nm) simultaneously
• All-day testing with 5 hours' continuous operation
• With interchangeable connectors, switch easily among FC / SC / LC / ST
• View measurement results in list or graph format
• Store up to 1000 data groups; manage them with Toolbox PC software



• Quickly identifies, locates and maps signal interference
• Performs comprehensive signal analysis for complete site profile and monitoring of signal environment
• Occupied Bandwidth, Channel Power and ACPR
• Dual spectrum and spectrogram measurements
• Verify RF transmission
