BAUR UL 30 Audio frequency system

• High-performance audio frequency transmitter up to 600 VA
• Frequency of 2 or 10 kHz, quartz-stabilised (other frequencies on request)
• Potential-free output
• Impedance adjustment in 8 steps from 0.3 to 300 O



• Fully automatic measurement sequence
• Suitable for mineral or silicone oils and easther liquids
• Reliable, reproducible measurement results using the latest measument technology
• Designed for daily countinous operations in laboratories



• Easy and quick cable fault location
• Light, compact and manageable
• Main unit for the tried-and-tested pre-location method
• Ideal for integration in measurement systems



• Compact, enclosed design in 19½ format
• Variable installation option with separate control and voltage unit
• Variable connection options to cable stations of different models



• Cable testing and dissipation factor diagnostics in one device
• Easy and quick test setup
• Automatic testing and diagnostic sequences
• Compact dimensions and lightweight



• Automatic or manual impedance adjustment
• Charging unit and rechargeable battery integrated; battery or mains operation
• Continuous or cyclical output
• Two output frequencies selectable



• Output energy up to 50 VA
• Automatic or manual impedance adjustment
• Charging unit and rechargeable battery integrated; battery or mains operation
• Continuous or cyclical output



• 6 output voltages up to max. 16 kV available
• Electromagnetically actuated surge switch
• Preselectable surge energy: 288 / 512 Ws (in all voltage ranges)
• Automatic discharge unit



• High surge voltage up to 32 kV
• Continuously adjustable voltage
• Voltage monitoring through kV meters with 3 measuring ranges
• Automatic discharge unit



• Initial rapid condition evaluation of switchgear and cable accessories during mains operation
• Ideal for quick checks of MV and HV switchgear
