ACUTE TL2118E Analizor logic 18-canale

• PC-based, USB2.0 interface / powered
• 2 channels (stackable to 12 channels)
• 1 GS/s sampling, 200 MHz bandwidth
• Data Logger (HD storage)
• Input Sensitivity : 2 mV/div
• Embedded 2-channel FG
• Built-in 5 DVM and 5 digital frequency counter
• Bus Trigger / Decode : ARINC 429, CAN, I²C, LIN, MIL-STD-1553, ProfiBus, SPI (2-Wire), UART, USB1.1, ...



• PC-based
• USB2.0 interface / powered
• 18 channels
• 4 GHz timing
• 200 MHz state analysis



• PC-based (USB2.0 interface)
• USB powered (2 USB ports needed for TS2212A)
• 2 channels (stackable up to 6 channels)
• 1 GS/s real-time sampling
• 200 MHz bandwidth
• 10K/64M points per channel



• PC-based, USB 3.0 interface/powered
• 200 MHz timing/state analysis
• Digital channels : 16 (Data), 1 (Clock), 2 (I²C)
• Memory : PC RAM
• Data logger
• Real time data display and post-capture waveform display
• Bus Decode : I²C, I²S, LIN2.2, SMBus, PWM, SMBus, SPI, UART, USB PD 2.0, ... (60+ decodes)



• 100 MHz Bandwidth
• 2 Channels (allows to stack up to max. 6 channels)
• 100MS/s Sample Rate
• 9 bit Vertical Resolution
• 64 K Memory Depth



• 200M bits data rate
• 200 MHz High Speed Internal Sequential Clock Rate
• 16 channels for editable digital pattern output



• 200 MHz Bandwidth
• 2 Channels (allows to stack up to max. 6 channels)
• 200MS/s Sample Rate
• 9 bit Vertical Resolution
• 64 K Memory Depth



• 50+12 Channels
• 100 M bits/s Data Rate
• 512K Pattern Memory Depth
• 1.5v~5.0v (adjustable 255 Level) Output Voltage



• 200 MHz Bandwidth
• 2 Channels (allows to stack up to max. 6 channels)
• 200MS/s Sample Rate
• 9 bit Vertical Resolution
• 512 K Memory Depth



• PC-based, 64 channels
• USB 3.0 interface, 12V power adaptor
• 32Gb total memory
• Protocol Analyzer:eMMC5.1, NAND Flash, SD3.0, SD 4.0 (UHS-II)
• Logic Analyzer:eMMC5.1, NAND Flash, SD3.0, Serial Flash, SPI NAND, SPI
