Reliably handle a wide range of high-current applications with 2000 A AC + DC true-rms, 1400 A AC, and 2000 A DC
The large 58 mm (2.3 in) jaw capacity is suitable for large or multiple conductors
High voltage measurement of 1000 V AC + DC true-rms, 600 V AC, and 1000 V DC allows the user to perform multiple tests with only one tool
Resistance to 400 Kohms coupled with a continuity beeper provide the convenience of a multimeter in a clamp meter
CAT IV 600 V, CAT III 1000 V rating for added user protection
In-rush current measurement captures �power-on’ surge current with accuracy and repeatability
Accurately measure frequency up to 1 kHz for optimum troubleshooting
Quickly analyze readings using the MIN, MAX, and AVG functions
A large backlit display allows for easy visibility in low-lit areas
Use the display hold feature to capture readings even when the display cannot be viewed
Use the low-pass filter to smooth out noisy loads and stabilize readings

Standard accessories

C43 Soft carrying case
6 AA batteries
TL224 1.5 m silicone rubber test leads
TP2 Test Probes
AC285 Alligator Clips
User manual
3 year warranty

More products FLUKE

INFRARED THERMOMETER WITH CONTACT THERMOCOUPLE FLUKE 566/ FLUKE 568

• Measure -40 °C to 800 °C /-40 °F to 1472 °F (568) or -40 °C to 650 °C/-40 °F to 1202 °F (566)
• Easily access advanced features with the soft-key buttons and dot-matrix display
• Measure smaller objects from further away, with a distance-to-spot ratio of 50:1 (568) or 30:1 (566)
• Compatibility with all standard miniconnector Type-K thermocouples allow you to preserve your thermocouple investments

FLUKE 700HTP-2 HYDRAULIC TEST PUMP FOR PRESSURE CALIBRATION

• hand operated hydraulic pressure pump
• designed to generate calibration pressures up to 10,000 psi/690 bar
• Variable size stroke adjustment, allows the user to vary the volume and pressure per stroke
• Integral pressure adjustment vernier knob for fine pressure adjustment
• Directly connection to pressure modules consolidates two separate pieces into one when performing pressure calibration and testing
• Two ¼ inch NPT pressure ports, one for reference (pressure module or gauge), one for UUT
• Improved priming
• Improved stroke limiting mechanism

FLUKE 721 PRESSURE CALIBRATOR

• 16 PSI (1.1 bar) or 36 psi (2.48 bar) low pressure sensor
• 7 high pressure ranges including 100, 300, 500, 1000, 1500, 3000 or 5000 psi (6.9, 20, 24.5, 69, 103.4, 200, 345 bar)
• Ideal for gas flow calibration (custody transfer) applications
• Two isolated, stainless steel, pressure sensors with 0.025 % accuracy
• Pt100 RTD input for temperature measurement, (probe optional)
• Measures 4 to 20 mA signals
• Internal 24 V loop power supply can power a transmitter under test
• Measure up to 30 V dc, check 24 V loop power supplies

INFRARED DIGITAL THERMOMETER FLUKE 62

• High-resolution optics
• High accuracy: 1 % and repeatability: 0.5 %
• MAX temperature display
• Laser targeting
• Backlit display
• Expanded measurement range up to 535 °C (999 °F)

FLUKE 1550C MEGOHMMETER INSULATION RESISTANCE 250V/ 5KV

• Resistance Test range: 1 TO
• Test voltage: 5 kV

FLUKE 1623-2 GEO EARTH GROUND RESISTANCE TESTER

• 3- and 4-pole Fall-of-Potential, earth resistance loop testing
• 4-pole Soil Resistivity testing
• Selective earth ground rod testing using 1 clamp
• Stakeless earth ground rod testing using 2 clamps
• IP56 rated for outdoor use
• Rugged carrying case
• USB data storage and transfer

AC VOLTAGE DATA ACQUISITION RECORDING KIT FLUKE FLK-CNX V3000 KIT

• True-RMS AC and DC voltage measurements to 1000V
• True-RMS AC and DC current with 0.01 mA resolution
• True-RMS AC voltage measurements to 1000V
• Memory recording up to 65,000 readings
• CAT III 1000 V; CAT IV 600 V; IP42

FLUKE 190-504 190-504/S HANDHELD SCOPEMETER OSCILLOSCOPE 4X500 MHZ

• 4-channels isolated 500MHz
• CAT III 1000V / CAT IV 600V safety rated
• Dedicated 5000 Count digital multimeter in two-channel models
• Advanced automatic measurements, power (Vpwm, VA, W, PF) and time (mAs, V/s, w/s)
• IP-51 rated for dust and drip proof to withstand harsh environments
• Isolated USB ports for memory devices and PC connectivity

DOCUMENTING PROCESS CALIBRATOR FLUKE 744

• 0 to 300 V DC/AC Voltage measure
• 0 to 15 V DC Voltage source / simulate
• 0 to 110 mA DC Current measure
• 0 to 22 mA DC Current source / simulate
• 0 to 11 kO Resistance measure / source / simulate
• 1 to 50 kHz Frequency measure / source / simulate
• PC interface and data logging
• Integrated HART communication

REMOTE AC CURRENT MEASUREMENT KIT WITH CURRENT CLAMP FLUKE FLK-CNX A3000 KIT

• True-RMS AC and DC voltage measurements to 1000V
• True-RMS AC and DC current with 0.01 mA resolution
• True-RMS AC current measurements to 400 A
• Memory recording up to 65,000 readings
• CAT III 600 V; IP42
