Generator analogic de functii 3 MHz TTi TG310

• CPX200 - compact dual output 2 x 175 watts
• CPX400A - compact dual output 2 x 420 watts
• CPX400D - compact dual output 2 x 420 watts
• CPX400DP- programmable dual output 2 x 420 watts



• 16 MHz sine and square
• 4-channel independent or linked
• 40 MSa/s sample rate
• 12-bit vertical resolution



• 30W to 130W Linear, Single, Dual & Triple Output
• Independent digital voltage and current meters for each output
• 4 digit resolution
• Switchable local or remote sensing
• Constant voltage or constant current operation



• 1MHz to 2700MHz frequency range
• Resolution bandwidths of 1MHz, 280kHz or 15kHz
• -96dBm typical noise floor at -20dBm reference level
• Measurement in dBm or dBµV, mV or µW
• Zero span mode with AM and FM audio demodulation



• Extends the output range of function generators
• 30 Volts peak to peak output swing
• DC to 1MHz bandwidth
• High impedance input, 0dB to +20dB gain
• 50 Ohm and 600 Ohm outputs
• 20dB swtitchable output attenuator



• Compliance quality measurements to EN61000-3-2 and EN61000-3-3
• Measures peak or rms voltage or current, real or apparent power, power factor, phase
• Tabular/histogram of 40 harmonics



• 100 Hz, 120 Hz, 1 kHz, 10 kHz Selectable Measurement Freq
• 0.1% basic measurement accuracy
• Dual 5 digit high brightness displays



• 40 MHz sine
• 50 MHz square
• 4-channel independent or linked
• 100 MSa/s sample rate
• 12-bit vertical resolution



• Provides an EN61000-3-2 compliant source
• 1000W power capability at 230V
• Up to 4·4A rms load current and up to 10A peak currents



• Frequency, period, pulse width, frequency ratio, duty cycle, and event counter modes
• DC to 6000MHz range, 0.001mHz resolution
• High impedance measurement up to 125 MHz
• AC or DC coupling, 1M/50Ohm selection, polarity invert
• Switchable attenuator, threshold control
