Sonda activa diferentiala osciloscop 200MHz Testec TT-SI200

Cod: Testec TT-SI200

Descriere

TT-SI 200 1:10, 200MHz

Bandwidth: 200MHz

Attenuation Ratio: : x10

Accuracy: ± 1%

Rise Time: 1,75ns

Input Impedance: 500kW / 7pF

Only connect to a grounded oscilloscope!

Input Voltage

Differential Mode: +-20V (DC + peak AC or rms)

Common Mode: +-60V (DC + peak AC or rms)

Absolute max. Voltage: +-60V (DC + peak AC or rms) CAT I

Output Voltage

Swing: ± 2V (into 50W load)

Offset (typical): <± 2mV

Noise (typical): 0,3mVrms

Source Impedance (typical): 50W

CMRR (typical): -80dB@100Hz, -50dB@10MHz
