Modul achizitie USB 64-canale 500kSa/s Agilent U2356A

• 40 Channel Single-Ended Multiplexer
• Single-wire switching for common-low applications
• 60 ch/s scanning
• Built-in thermocouple reference junction



• RF switching to 3 GHz
• Dual 1x4 50 ohm RF switch multiplexer to 3GHz
• Off channel termination
• 30V, 1A, 1W switching
• 60 dB isolation at 1 GHz



• 32 Two-wire cross points in 4x8 configuration
• DB25 connector
• High-speed USB 2.0 (480MBits/s) TMC488.2 compatible
• Standalone and Modular capabilities



• 20 Form A channels up to 5A, 150W
• Armature latching relays, with relay counter
• Temperature sensor for overheating conditions



• 68-channel portable logic analyzer
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth



• High-speed USB 2.0
• 16-bit resolution
• 16 SE/8 DI multiplex analog input channels
• Up to 250 kSa/s sampling rate
• 2 16-bit analog output channels
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 1 MHz to 3 GHz, with 100 kHz steps
• 1% basic accuracy
• Wide impedance measurement range from 200 milliohm to 3 kohm



• 250 kHz to 20 GHz, 31.8 GHz, 40 GHz, 50 GHz or 67 GHz operational to 70 GHz
• 0.001 Hz resolution
• +23 dBm @ 20 GHz, +17dBm @ 40 GHz, +14 dBm @ 67 GHz output power (typ); > +30 dBm (typ) with Option 521.
• AM, FM, ØM, pulse, and scan
• Extendable to 75, 90, 110, 140, 170, 220, 325, or 500 GHz



• 1 kHz to 660 MHz
• 1 or 2 Channels(order 2 x 81132A modules)
• 500 ps typ.fixed
• Up to 2.5 Vpp into 50 O



• Network Analyzer 2 MHz to 4 GHz/ 6 GHz
• Transmission/reflection (S21, S11) or full two-port (S21, S11, S12, S22)
• Cable and Antenna Analyzer 2 MHz to 4 GHz/ 6 GHz
• Power Meter 9 kHz to 24 GHz
• Vector Voltmeter 2 MHz to 4 GHz/ 6 GHz
