Pulse Generator 0.1Hz-10MHz TTi TGP110

Code: TGP110




Datasheet PDF, 0.11 Mb

Description

  • 0.1Hz to 10MHz frequency range
  • Independent control of pulse frequency, width and delay
  • 50ns minimum pulse width
  • Squarewave, double pulse & delayed pulse modes
  • Free-run, gated and triggered modes
  • 50 Ohm output: 0.1V to 10V amplitude
  • TTL/CMOS and Sync outputs
  • Low-cost
