Cable TV Level Meter for Analog and Digital Signal DigiairPro CATV

Description

• Perfect for digital CATV installations (QAM).

• Handy spectrum-analyzer for frequency 45-860MHz.

• Easy digital readout of MER, BER and Constellation diagram.

• QAM16, QAM32, QAM64, QAM128 & QAM256.

• Analog signal level reads out in dBuV, dBmV and dBm with maxhold function.

• Presents one channel readout with high resolution or six channels simultaneously or the complete spectrum.

• Very sensitive, easy to maximize weak and strong signals.

• Built in beeper (pitch tone) and maxhold function.

• Tilt function.

• Replacable, rechargeable battery (8x AA 1200mA).

• Power supply and car-charger enclosed.

• Rubber carrying-case enclosed.

Emitor´s DIGIAIR Pro CATV is developed in Sweden for exact installation and adjustment of cable networks.

This is made for both analog (dBuV) and digital (MER and BER). DIGIAIR Pro CATV is microprocessor controlled, making it very reliable and accurate.

Signal strength is presented on the LCD-display. In analog mode it shows a single channel or six channels at the same time. You can also choose to view the signal in spectrum mode.

In digital mode it displays the BER (bit error rate) and MER (modulation error rate). Readout of UCB (uncorrected bits) and CB (corrected blocks) is also easy to do.

Constellationdiagram can be viewed upon.

Furtermore DIGIAIR Pro CATV present pitchtones (the higher tone the stronger signal) on a loudspeaker.

DIGIAIR Pro CATV is very sensitive and can detect even the weakest signals.

DIGIAIR Pro CATV is charged via an external DC power-source of 13,5 -18 volt.

Even though the DIGIAIR Pro CATV has a lot of functions it is still very easy to use and has a very compact design.

DIGIAIR Pro operates with 8xAA rechargeable batteries.

The unit will works for at least 2 hours with fully charged batteries.
