The BITE5 and BITE5 Advanced battery testers let you perform simple tests to quickly evaluate the state of health of lead-acid (VLA and VRLA), NiCd, and lithium-ion batteries. Both instruments have an easy-to-use touch-screen interface and support impedance testing and discharge testing when used in conjunction with a load bank. The BITE5 Advanced allows you to monitor batteries and cells during recharging and test parallel strings without segmenting. With the BITE5, you can perform tests on modules up to 200 V and, with the BITE5 Advanced, on modules up to 500 V.

Measurement options provided by the BITE5 include cell impedance, cell voltage, ripple voltage, AC ripple current and DC float current. The BITE5 Advanced supports all of these tests and also has provision for accurately measuring inter-cell (strap) resistance.

For impedance tests, you can set pass, warning, and fail limits for impedance and voltage. For discharge tests – and recharge tests with the BITE5 Advanced only – measurements are recorded throughout the full discharge or recharge period. Trends can be displayed on the instrument’s touch screen, and stored results can be downloaded via a USB cable or an SD card for further analysis and archiving. Wireless transfer of data to Megger’s PowerDB software suite is also supported.

Both the BITE5 and BITE5 Advanced support voltage measurement up to 1000 V DC and 600 V AC, which means you can use them to measure solar combiner boxes and check the input and output voltages of inverters used in renewable power systems. An additional feature of the BITE5 Advanced is an RFID tag reader, which allows the instrument to recognise assets without requiring manual data entry.

Standard accessories

Description Part number

BITE5 BITE5

Included accessories

Duplex probes (with temperature probe) 90043-241

Voltage test leads 90037-576

Charger 90039-077

Neck strap 90037-529

Zero bar 90037-575

16 GB microSD card 90037-572

microSD card USB reader 90037-571

USB cable 90037-569

Stylus 90037-570

Carry bag 90037-573

Pouch bag 90037-574

Optional accessories (For Model A BITE5)

Concentric probes (1/2” tip) 90037-560

Concentric probes (1” tip) 90037-565

100 A AC current clamp MCV-100B5

1000 A AC/DC current clamp MCCV-1KDC-B5

3 meter right angle probe 90041-193

3 meter straight probe 90041-194

3 meter clip on probe 90042-655

Extension kit with straight probe 1016-069

Extension kit with 90 degree probe 1016-068

Extension kit with straight and 90 degree probes 1016-070

Optional accessories (For Model B BITE5)

Concentric probe (1/2” tip) 90043-242

Concentric probe (1” tip) 90043-243

100 A AC current clamp MCV-100B5B

1000 A AC/DC current clamp MCCV-1KDC-B5B

3 meter right angle probe 90043-244

3 meter straight probe 90043-245

3 meter clip on probe 90043-246

Extension kit with straight probe 1016-066

Extension kit with 90 degree probe 1016-064

Extension kit with straight and 90 degree probes 1016-067

Description Part number

BITE5 Advanced BITE5-ADV

Included accessories subhead

Duplex probes (with temperature probe) 90043-241

Voltage test leads 90037-576

Charger 90039-077

Neck strap 90037-529

Zero bar 90037-575

16 GB microSD card 90037-572

microSD card USB reader 90037-571

USB cable 90037-569

Stylus 90037-570

Carry bag 90037-573

Pouch bag 90037-574

Optional accessories

Concentric probe (1/2” tip) 90043-242

Concentric probe (1” tip) 90043-243

100 A AC current clamp MCV-100B5B

1000 A AC/DC current clamp MCCV-1KDC-B5B

3 meter right angle probe 90043-244

3 meter straight probe 90043-245

3 meter clip on probe 90043-246

Extension kit with straight probe 1016-066

Extension kit with 90 degree probe 1016-064

Extension kit with straight and 90 degree probes 1016-067

Backpack for BITE5 (with BITE5 pouch) 1015-611
