FET Multiplexer Module 40/80 optically isolated channels Agilent 34925A

• Quad 4-channel multiplexers
• DC to 3 GHz, 50 Ohm
• High isolation, low VSWR
• 30V, 0.5A, 10W switching
• SMA connectors



• 68-channel portable logic analyzer
• 48-channel pattern generator
• 4 GHz (250 ps) timing zoom with 64 K memory
• 1.0 GHz / 500 MHz (half / full-channel) conventional timing with deep memory
• up to 450 MHz State clock rates
• up to 500 Mb/s Data rates
• up to 32 M acquisition memory depth



• 500 MHz bandwidth
• 2 analog channels plus 16 digital channels
• 2 GSa/s per channel sample rate, 4 GSa/s half-channel interleaved mode

• 200 MHz bandwidth
• 2 channels
• 32 Mpts memory depth, 64 Mpts interleaved single-shot
• 1 GSa/s sample rate on 2 channels interleaved, 500 MSa/s each channel

• 40 2-wire channels or 80 1-wire channels
• Mixed 2- or 4-wire configurations
• High-speed reed relays, with relay counter



• Connect multiple instruments to multiple points for automated test applications
• Ultra high-density, 4x64 2-wire matrix
• 100Vrms
• 0.5A switch/carry current
• 10W max power
• High-speed reed relays



• 100 MHz bandwidth
• 4 analog channels
• 2 GSa/s per channel sample rate, 4 GSa/s half-channel interleaved mode



• 350 MHz bandwidth
• 2 GSa/s sample rate
• 2 analog plus 16 digital channels
• Standard 8 Mpts MegaZoom III deep memory



• High-speed USB 2.0
• 16-bit resolution
• 64 SE/32 DI multiplex analog input channels
• Up to 500 kSa/s sampling rate
• 2 12-bit analog output channels
• 1 MSa/s analog output update rate
• 24-bit programmable TTL input/output channels



• 9 kHz to 3.0 or 7.5 GHz Frequency range
• 10 MHz (standard), 25 MHz (optional) analysis bandwidth
• Basic EMI precompliance measurement capability available
• Standards-based PowerSuite: channel power, OBW, ACP, CCDF, SEM
