The LeckOmiO is a combination device for various applications in the gas installation. It Allows detection of smallest gas leaks as well as rapid and precise pressure measurements, ease of use and a wide range of applications. Through the display of minimum and maximum values??, as well as measurement times and start and end pressures in pressure tests, it offers numerous advantages in handling. The following operating modes are selectable from the menu:

Pressure Test display of starting pressure, final pressure, measurement time and pressure drop, as well as minimally and maximum pressure value.

Regulator Test display of the outgoing pressure, closing pressure, safety pressure release valve response pressure and leak-proof completion, upper and lower deactivation of safety shut-off valve and leak-proof completion.

Load test according to TRGI Menu-driven procedure with individual Adjusting of the measuring time to the requirements of the TRGI load testing

Tightness test according to TRGI Menu-driven procedure with individual Adjusting of the measuring time to the requirements of the TRGI tightness testing

Building inspection detection of smallest leaks in plumbing lines and connections. In addition to the optical and acoustic signal a vibration alarm is available.

Settings Custom configuration of the operating parameters such as the measuring unit, automatic switch off or the duty cycle of the backlight to the user�s requirements.

Adjustment Sensor sensitivity test and calibration of the device according to DVGW Note G 465-4 by applying test gas and set point adjustment by pressing a button

Features:

Rugged hand-held instruments with ergonomic aluminum housing
Wide range of applications in the gas and water installation
Load- and tightness tests according to TRGI
Powerful gas detector with vibration alarm and digital display reading for gas leak detection
High contrast LCD display with backlight for an optimal presentation of all measured values
Easy replacement of batteries with innovative battery Management
Systematic evaluation of the measured data using Esders PC-1 software
Graphical printout on site on mobile printer
Simple operation with intuitive menu navigation Practical accessories for all applications

More products ESDERS

ESDERS SIGI EX FLAMMABLE GASES TESTER

• Improved sensor technology and adjustment options
• Increased operating temperature range of -20 to +50 ° C
• By up to 44% larger display area for better readability
• Red backlight for improved perception of alarm messages

ESDERS HUNTER GAS LEAK DETECTOR AND ANALYZER

• Cast carpet mat free from the material wear common in deep drawn mats
• Stabilising mould elements enable optimal fit on the ground and enable the carpet to be pulled backwards
• Comprehensive flow channels for sampling

ESDERS MULTI GAS DETECTOR H2S CO O2 LEL

• 2 month battery life on a single charge (infrared version)
• Compact and lightweight
• Low maintenance cost
• Simple to use
• LEL sensor (IR) does not require oxygen

ESDERS GOLIATH GAS ANALYZER

• Time-tested Esders operation concept.
• Very quick initial break-in phase after being switching on or changing application.
• Extremely short reaction times when measuring CH4 and CO2 in all concentrations.
• Oxygen and up to 3 toxic gas sensors are available as an option.
• Ethane analysis with automatic measurement result assessment can be integrated.
• Optional pressure measuring up to 2,000 hPa.

ESDERS GAS STANDPIPE

• Practical system with wide application
• Easy adaptation to many thread sizes, drilling saddles and fittings -directly or via electrically conductive tube
• Rapid extraction of gas by using the Venturi nozzle
• Flame arrestor for burning off the gas safely

ESDERS VIBRAGAS

• Rugged hand-held instruments with ergonomic aluminum housing
• Wide range of applications in the gas installation
• Powerful gas detector with vibration alarm and digital display reading for gas leak detection
• High contrast LCD display with backlight for an optimal presentation of all measured values

ESDERS GOLIATH BIOGAS ANALYZER

• Use of infrared sensors for CH4 and CO2 guarantee fast run-in period and extremely short response times and exclude cross-sensitivities to other gases.
• An oxygen and a hydrogen sulphide sensor are offered as an option.
• The measurement range for H2S is 0 to 2,000 ppm and cover the requirement for measurements at biogas plants ideal.

ESDERS SAFE ETHANTEST

• Taking the service box to the measurement site
• Activate device and connect sensor
• Feed sensor into sensor hole and start analysis at the touch of a button
• SAFE absorbs a gas sample and displays its concentration in vol.%
• The gas sample passes through the chromatographic column and the display of methane and ethane (if applicable) takes place

ESDERS ELLI PORTABLE LASER METHANE CH4

• Colored LCD touch screen
• Selective detection of methane
• Integrated GPS and bluetooth functionality
• User-defined alarm threshold
• Rugged housing design IP54

ESDERS SINGLE GAS

• Operational life of two years
• Full factory warranty throughout the life of 24 months
• Measurement of H2S, CO and O2 ensures the safety of the worker
• Reduces training time
• Loud audible alarm, bright visual alarm, vibrating alarm
