EMI & EMC Test Broadband Antenna 20MHz..3GHz Aaronia HyperLOG 20300

Code: Aaronia HyperLOG 20300




Datasheet PDF, 0.7 Mb

Description

  • Compatible with any Spectrum Analyzer brand
  • Design: Biconical & Logarithmic-Periodic (combination)
  • Frequency range: 20MHz to 3GHz
  • Max. input power: 310W AM
  • Immunity test field strength:10V/mm
  • Nominal impedance: 50 Ohm
  • Accuracy: 0,3dB
  • VSWR: <2:1 (typ.)
  • Gain: 6dBi (typ.)
  • Antenna factor: See data sheet graph
  • RF connection: N (f) or SMA (see optional adapter)
  • Calibration points: 2970 (1MHz-steps)
  • Dimensions (L/W/D): 1300x1400x650mm
  • Weight: 5,3kg
  • Warranty: 10 years



Highlights:

  • Usable for highly professional EMC/EMI pre-compliance tests
  • Very high accuracy to be used as a reference antenna
  • Suitable for immunity measurements
  •  Includes exhaustive calibration data (on CD)
  • High quality rubber paint for perfect antenna protection
  • Wide bandwidth
  • Very high gain over the total frequency range
  • Coverage of various mobile radio frequency ranges
  • Perfectly suitable for field-strength and EMC measurements due to high precision
  • Can be used in the lab and for open-field application





Examples for possible analysis and measurements within frequency range (20MHz - 3GHz):

  • Highly professional Pre-Compliance-Test even for very low signals
  • Immunity measurements
  • Radio & TV
  • Tetra/BOS
  • ISM434
  • LTE800
  • ISM868
  • GSM900
  • GSM1800
  • GSM1900
  • DECT
  • UMTS
  • WLAN
  • Microwave
  • Bluetooth
  • WiFi
  • LTE2.6
  • etc.





Standard accessories

  • HyperLOG 20300 EMI test antenna for EMC/EMI tests
  • Typical calibration data with 2970 calibration points (1MHz steps!) on CD
  • Heavy carrying case
