4 x 32 Quad Matrix Module Agilent 34934A

Code: Agilent 34934A




Datasheet PDF, 1.43 Mb

Description

  • 4x128, 8x64 or 16x32 1-wire configurations
  • 4x64 or 8x32 2-wire configurations
  • 100V, 0.5A switch/carry current
  • Reed relays with high speed path switching
  • Relay cycle counter
  • Row expansion and row disconnect for creating larger matrices
  • Row protection bypass switch for low level measurements
  • Optional configuration block or high density screw terminal block
  • 25 MHz Bandwidth
