GTEM Test Cell for EMC Radiated Emissions & Immunity ETS-Lindgren 5407

Code: ETS-Lindgren 5407



Datasheet PDF, 0.13 Mb

Description

  • Frequency: DC - 20 GHz (RI) 2 9 kHz - 5 GHz (RE) 1
  • Post Production
  • For all Phases of EMC Testing - Design Qualification - Pre-Compliance
  • Full Compliance IEC 61000-4-3 ANSI C63.4



Electrical Specifications

Feed Connector Type

cw 7/16 DIN to N Adapter

Field Uniformity

f £1 GHz, 0 -6dB

Frequency

9 kHz - 5 GHz (RE) 1
DC - 20 GHz (RI) 2

Input Impedance

50 ?

Maximum CW Input

200 (500 W with optional blower) W

Shielding Effectiveness

10 kHz - 1 GHz
From Internal E-Fields 80 dB min

VSWR Maximum

All Other Freq £1.50:1
Characteristic Freq £1.75:1

VSWR Typical

All Other Freq 1.30:1
Characteristic Freq3 1.75:1



Standard accessories

  • Two AC receptacles
  • ETS-Lindgren absorber material
  • Customer will need to provide manpower and specific tools
  • Three N-type connectors
  • One fiber optic penetration
  • Individually characterized with results of TDR and VSWR tests
  • Manual emissions correlation software (on request)
  • 5400 GTEM! Series manual
  • Shipped disassembled
  • Working supervisor for installation is provided. (Outside North America, call factory)
  • 7/16" DIN to type "N" adaptor
  • Primary door 27" W x 29.1" H clear opening (68.6 cm x 74.7 cm)
  • Mobile base with locking casters
  • One 20 amp, 2 line filter


Recommended options

  • Blank panel with frame
  • Illumination assembly
  • Manual EUT manipulator
  • Panel with connectors and frame
  • Shielded Window for primary door
  • Blank panel
  • Blank panel with connectors
  • Blower assembly
  • Three Position Ortho-Axis Pneumatic Manipulator (light duty)
