Ametek WT Series Digital Pressure Gauge

• Wide selection of sensors (straight, 90°, cabled, etc.) to fit your application
• Useful features like hold, and min / max
• Power with a single 9V battery, or external 9V supply



• One year accuracy to ½ 0.004°C
• System accuracy with STS Series temperature sensors to ½ 0.03°C
• Wide Temperature Range of -200 to 750°C (-328 to 1382°F)
• Resolution to 0.001°C



• Read voltage (10V and 100V DC ranges to ½ 0.005%)
• Read current (0 to 50mA to ½ 0.01%)
• 24VDC loop power supply
• Selectable 250 ohm HART resistor



• Measure Current to 24mA with ½ 0.01 % of reading accuracy
• Measure Voltage to 30VDC with ½ 0.01 % of reading accuracy
• 24VDC Loop Power Supply
• User defined step and ramp functions



• Differential Pressure with up to 0.025% of reading accuracy
• Switch, Voltage, Current, and Temperature
• 500 000 data points - 10 readings per second from 2 modules



• Multi-hole and/or insert kits
• Input for external reference sensor on all C models
• MVI circuitry ensures stability despite mains supply variations



• Gauge / Absolute Pressure Datalogger to 15 000 psi / 1000 bar / 100MPa
• Differential Pressure with up to 0.025% of reading accuracy
• Switch, Voltage, Current, and Temperature
• 500 000 data points - 10 readings per second from 2 modules



• Automatic procedures reduce human error
• Dedicate one input channel to a reference sensor with accuracy to 0.026°C
• Uses True Ohm technology to eliminate EMF from cables, sockets, and sensors



• 0.1 % of reading accuracy
• Batteries and digital communications are accessible from the front
• Rugged "Wally Box" gauge can withstand dropping and accidental over-pressurization



• Source and Measure current to 24 mA with ½ 0.05% of full scale
• Measure voltage from 0 to 45 VDC with ½ 0.5 VDC
• 200 hours of life using 4 x AA batteries
