AARONIA BPSG6 OEM RF Signal Generator 6GHz

Code: AARONIA BPSG6 OEM

Datasheet

PDF, 0.68 Mb

Description

Frequency range: 23.5 MHz to 6GHz
Up to +18dBm output power (female SMA-connector)
Smallest power level: -48dBm
Up to 65dB dynamic range
Frequency accuracy: 15Hz (<100MHz), 150Hz (<1GHz), 600Hz (<4GHz)
Modulations: AM, FM, PM
Mounting drillings from all sides. Perfect for OEM installation
Onboard TCXO for very high frequency accuracy
Can be connected to external reference clock for even higher accuracy (female SMA-connector)
Onboard CPU and memory for intelligent self-running profiles
Stand alone operation (no PC or USB connection required)
Battery operation up to 4h
USB connector for realtime PC control or for storing programs
Incl. 12V power supply for continuous operation
Can be operated from 12V Car and Truck power system
Very small form factor, 81x49x24mm only
Very lightweight, only 150gr incl. battery

RF Signal Generator BPSG4 OEM

The new signal generator series BPSG from Aaronia offer an unprecedented mix of performance, design and functions, especially in its price category.

Due to the OEM housing the BPSG4 OEM is perfect for installation in existing systems. The provided screw holes make installation here immensely.

The BPSG4 OEM offers to adjust the frequency (between 35MHz to 4,4GHz) and power level (-48dBm to +17dBm, 0,5dB steps) freely.

Highlights

World smallest battery powered and intelligent stand alone RF generator up to 4,4GHz

Generator can be programmed with simple or very complex batch programs which start automatically after every power on (e.g. generate a fixed frequency and level OR start a specific sweep etc. )

Can be used as mini RF frequency and power level calibrator

Stable frequency generation, thanks to the internal TCXO timebase

Extremely compact and lightweight (150g)

Incl. PC control software

Standard accessories

BPSG6 OEM Signal Generator with integrated battery
transport case
International Charger/Power Supply
SMA Tool
USB-Cable
Control Software
